Mini Garden Tractors Loader

Mini Garden Tractors Loader thumbnail-1
Mini Garden Tractors Loader photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Weifang Fumei Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) according to the tractor
Certificate CE
Brand Name FM
Model Number FLD series and LW series
Place of Origin Shandong, China
After-sales Service Provided No overseas service provided

Specifications

Name: Front Loader and Backhoe
Match power: 20-165hp
Bucket type: 4 in 1 or normal

Mini Garden Tractors Loader

Front end loader specifications

Technical Data

FLD20C/D

FLD40C/D

FLD60C/D

FLD80C/D

FLD120C/D

Max.Lift Height-Measured at Pivot Pin(mm)

2100

2400

2700

3020

4200

Max.Lift Height-Under Level Bucket(mm)

1700

2000

2300

2500

3600

Max.Dump reach(mm)

600

800

930

1020

1200

Dump angle(°)

45

42

42

42

42

Reach with Bucket on ground(mm)

1560

1830

2000

2200

2400

Rollback angle on ground(°)

26

26

27

28

28

Max.Digging depth(mm)

100

100

110

110

110

Rated Load(kg)

260

360

600

800

1000

Bucket Capacity (m³)

0.2

0.3

0.46

0.6

0.9

Recommended Tractor HP

20-35

35-55

55-85

75-105

110-165

 Backhoe specifications

Model

LW-6

LW-7

LW-8

Max.digging depth (mm/ inch )

1850/ 73

2150/ 85

2640/ 1046

Max.digging depth flat bottom (mm/ inch )

1600/ 63

2000/ 79

2500/ 98

Max. digging height (mm/ inch )

2500/ 98

3400/ 134

3510/ 138

Loadover heith (mm/ inch )

1400/ 55

1760/ 69

2000/ 79

Transport height (mm/ inch )

1733/ 68

1878/ 74

1952/ 77

Ground clearance (mm/ inch )

280/ 11

290/ 11

290/ 11

Boom pivot height (mm/ inch )

420/ 16

500/ 20

500/ 20

Straight wall digging depth (mm/ inch )

895/ 35

1134/ 45

1446/ 57

Max.digging radius (mm/ inch )

2800/ 110

3360/ 132

3930/ 155

Loading reach (mm/ inch )

1044/ 411

1187/ 47

1945/ 77

Bucket rotation(angle)

160

160

160

Swing Arc(angle)

140

140

140

Mini Garden Tractors Loader

Mini Garden Tractors LoaderMini Garden Tractors LoaderMini Garden Tractors Loader

Mini Garden Tractors Loader
