Home > Industrial Equipment & Components > Refrigeration Equipment > Industrial Air Conditioner > 8000m3/h Airflow Environment Friendly Indirect Evaporative Cooler
8000m3/h Airflow Environment Friendly Indirect Evaporative Cooler
US$ 1 - 10,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Evaporative Air Cooler
Place of Origin:
Fujian, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
6000m3/h Airflow Combined Type Indirect Cooler Add HumidtyUS$ 1 - 10,000MOQ: 1 Unit -
Hot Seller Indirect Evaporative Cooler AJL06-FH31AUS$ 1 - 10,000MOQ: 1 Unit
-
Easy Maintenance Indirect Evaporative CoolerUS$ 1 - 10,000MOQ: 1 Unit
-
6000m3/h Airflow Combined Dew Point Indirect Evaporative CoolerUS$ 1 - 1,000MOQ: 1 Piece
-
2000m3/h Airflow Combined Dew Point Indirect Commercial Air CoolerNegotiableMOQ: 1 Unit
Condition
New
Type
Evaporative Air Cooler
Place of Origin
Fujian, China
Brand Name
Aolan
Model Number
AJL08-FH10A
Operating Voltage
Other, 220V
Mounting
Ceiling Mount
Certification
CE
After-sales Service Provided
Overseas third-party support available
high cooling efficiency Dew Point Indirect Evaporative Cooler
AJL08-FH10A
| Model AJL05-FH31A ~ AJL20-FH31A Combined Indirect Evaporative Air Conditioning | |||||||
| FOB Fuzhou | |||||||
| Structure | horizontal type | ||||||
| Function | cooling + humidifying | ||||||
| Net weight(kg) | 1150 | 1230 | 1430 | 1660 | 2200 | 2550 | 3011 |
| Input power(kW) | 2.47 | 2.85 | 4.05 | 5.55 | 6.13 | 8.18 | 11.44 |
| Rated supply air (m3/h) | 5000 | 6000 | 8000 | 10000 | 12500 | 15000 | 20000 |
| Nominal cooling capacity(kW) | 30 | 36 | 48 | 60 | 75 | 90 | 120 |
| Excess pressure(Pa) | 350 | 350 | 400 | 400 | 400 | 400 | 400 |
| Power supply(V/Hz) | 380/50 | ||||||
| Rated currency(A) | 6.8 | 8.8 | 11.6 | 15.4 | 17 | 25 | 31 |
| EER(kW/kW) | 12.1 | 12.6 | 11.9 | 10.9 | 12.2 | 11 | 10.5 |
| Wet bulb efficiency (%) | 120 | ||||||
| Fresh air rate(%) | 100 | ||||||
| Noise dB(A) | ≤67 | ≤69 | ≤70 | ≤71 | ≤75 | ≤72 | ≤74 |
| Controller type | 2012 LCD control | ||||||
| Fresh air filter section | |||||||
| Filter type | Plate-type (plate-fin) | ||||||
| Filter material | Aluminum frame + fiber + protecting net | ||||||
| Filter efficiency/gravimetric method | 40% | ||||||
| Filter grade | G4 | ||||||
| Evaporative cooling section | |||||||
| Cooling core | Combined module | ||||||
| Cooling core material | Macromolecule + wood pulp fiber | ||||||
| heat transfer area(m2) | 480 | 576 | 770 | 960 | 1200 | 1440 | 1920 |
| Water consumption(m3/h) | 0.13 | 0.16 | 0.22 | 0.27 | 0.34 | 0.4 | 0.54 |
| water supply pressure(MPa) | 0.15~0.30 | ||||||
| Water fender | horizonal | ||||||
| Water fender material | wood pulp fiber | ||||||
| water fender thickneess (mm) | 50 | ||||||
| Supply air section | |||||||
| Fan type | centrifugal fan with double air inlet | ||||||
| Fan model | 4.5# | 4.5# | 4.5# | 4.5# | 6.3# | 6.3# | 6.3# |
| Fan airflow(m3/h) | 7500 | 9000 | 12000 | 15000 | 18750 | 22500 | 30000 |
| Fan full pressure(Pa) | 670 | 680 | 760 | 800 | 750 | 770 | 830 |
| Blade type | forward curved multi-blades | ||||||
| Blade material | galvanized sheet | ||||||
| Volute material | galvanized sheet | ||||||
| Fan RPM(r/min) | 910 | 910 | 915 | 885 | 675 | 668 | 647 |
| L (mm) | 4178 | 4425 | 4874 | 5349 | 6590 | 7271 | 8394 |
| L1 (mm) | 1195 | 1518 | 1918 | 2312 | 2835 | 3436 | 4558 |
| L2 (mm) | 2160 | 2160 | 2160 | 2160 | 2760 | 2760 | 2760 |
| W (mm) | 2100 | 2100 | 2100 | 2100 | 2100 | 2100 | 2100 |
| H (mm) | 2032 | 2032 | 2282 | 2282 | 2362 | 2482 | 2482 |
| H1 (mm) | 1456 | 1469 | 1599 | 1556 | 1649 | 1656 | 1656 |
| H2 (mm) | 1400 | 1400 | 1400 | 1534 | 2132 | 2232 | 2232 |
| A*B (mm) | 630*320 | 630*320 | 800*400 | 800*400 | 800*500 | 1000*630 | 1000*630 |
| C*D (mm) | 500*320 | 500*320 | 630*400 | 630*400 | 800*400 | 800*630 | 800*630 |
| E*F (mm) | 800*500 | 800*500 | 1000*630 | 1000*630 | 1000*630 | 1250*1000 | 1250*1000 |
| Net weight (kg) | 1150 | 1230 | 1430 | 1660 | 2200 | 2550 | 3011 |
