Stainless Steel Chinese Herb Grinder Machine/Chinese Herbal Grinder :
Features of the chinese herbal grinder machine :
1.Application: It is widely used in feed, chemical, abrasive and agricultural industries.
2.Feeder: has frequency control of motor speed and electromagnetic coupling for choice, that the speed of feed
could be adjusted.
3.Structure:“U” shaped double grinding structure, increase the beating frequency of product , guarantee the
more uniform particle size, also increase the output.
4.Advantage:equipped with safety control system ,high capacity,smooth running,long service life.
5.Material: made in high quality steel
6.The following form is under the condition:raw material is corn,water content ≤14 % , the diameter of sieve hole
is 1.0-2.0mm.
Technical Parameters of chinese herbal grinder machine :
Mold |
Output capacity(t/h) |
Main motor power(kw) |
Hammer No.(pcs) |
Diameter of the Rotor(mm) |
speed of main shaft (r/min) |
width of chamber(mm) |
Dimension (mm) |
line speed of hammer(m/s) |
Weight(kg) |
|
SFSP 66x60 |
2.5-9 |
55/75 |
64 |
660 |
2970 |
600 |
2115×1340×1455 |
102.58 |
1740-1780 |
|
SFSP 66x80 |
5-13 |
90/110 |
88 |
660 |
2970 |
800 |
2620×1340×1455 |
102.58 |
1852-1992 |
|
SFSP 66x100 |
7-18 |
132/160 |
128 |
660 |
2970 |
1000 |
3020×1345×1455 |
102.58 |
2040 |
Pictures for chinese herbal grinder machine :
Photo of chinese herbal grinder machine production line:
We also produce following products:
Operating instructions for chinese herbal grinder machine :
1.The operator should understand the chinese herbal grinder machine structure, and be familiar with the
machine performace and operation methods.
2. Please carefully check each connection parts to avoid loose phenomenon.
3.With uniform feeding during the production rather than suddenly more or less to guarantee the motor work
under rated load.
4.If strong vibration appears in the operation process, you should immediately stop the machine and find out
the reasons, then continue .
About our Service:
1.The operator should understand the poultry/animal feed mixer grinder machine structure, and be familiar
with the machine performace and operation methods.
2. Please carefully check each connection parts to avoid loose phenomenon.
3.With uniform feeding during the production rather than suddenly more or less to guarantee the motor work
under rated load.
4.If strong vibration appears in the operation process, you should immediately stop the machine and find out
the reasons, then continue .
