CE Approved 1-2 T/H Cheap Wood Chipper Shredder :
Feature of cheap wood chipper shredder :
1.Component: base frame, inlet cutting blades, knives, plates, shells, and electronic control.
2.Capability: produce chips of different sizes and thickness.
3. Application: chip logs, slab, veneer, bamboo, brushwood, corn stalk, cotton stalk, reed and other
non wood fiber stalk into requirement size;
4. Specification of wood: length 15~20mm thick 3~5mm, width is not limited, but also do not exceed 20mm.
Wood chip rate request is greater than 85%, skin pass rate requirement is greater than 75%. Technical
Technical Parameters of cheap wood chipper shredder :
Mold |
Output capacity(t/h) |
Main motor power(kw) |
Weight(kg) |
Main motor speed(r/min) |
Knives diameter(mm) |
Blade size(mm) |
R-500 |
1-2 |
7.5 |
120 |
600 |
500 |
3 |
R-600 |
2-3 |
15 |
380 |
650 |
600 |
2-4 |
R-700 |
3-5 |
22 |
480 |
600 |
700 |
2-4 |
R-800 |
5-6 |
30 |
550 |
550 |
800 |
4 |
R-950 |
6-8 |
37 |
800 |
550 |
950 |
4 |
R-1100 |
8-12 |
45 |
1650 |
600 |
1100 |
4 |
R-1210 |
10-12 |
75 |
2100 |
600 |
1210 |
4 |
R-1410 |
15-20 |
90 |
2800 |
600 |
1410 |
4 |
Details for cheap wood chipper shredder :
Turn-key example for cheap wood chipper shredder :
Raw material for cheap wood chipper shredder :
Final products of cheap wood chipper shredder :
Packing details for cheap wood chipper shredder :
1. Wooden or metal case according to specific size of each cheap wood chipper shredder, we twine thick
plastic coating for each machine.
2. Tight the equipment in the truck without space to ensure no rubbing during the transportation.
We also produce following products:
Operating instructions for cheap wood chipper shredder :
1.The operator should understand the cheap wood chipper shredder structure, and be familiar with the
chipper machine performace and operation methods.
2. Please carefully check each connection parts to avoid loose phenomenon.
3.With uniform feeding during the production rather than suddenly more or less to guarantee the motor work
under rated load.
4.If strong vibration appears in the operation process, you should immediately stop the machine and find out the
reasons, then continue .
About Richi:
Henan Richi Machinery Co., Ltd was established in 1990.
After 23 years’ development and innovation since our factory established, we are becoming more and more
professional in manufacture and installation. During those years, our factory have obtained over 20 Product
Patents in the pellet series machines, such as in the crusher, curing machine, water feeder, and the
precleaners.The detailed patent numbers can be found in our patent column. (Patent No.such as:
ZL 2012 2 0349402.9, ZL 2012 2 0349367.0,ZL 2011 2 0290111.2,ZL 2011 2 0290114.6)
About our Service:
1.We insist on "Quality is the soul of company", we own outstanding R&D team with the sense of innovation and
cooperation.
2.Our professional service includes: Free training, Guidance Installation and Debugging.
3.Guaranteed Time: One Year (Calculated from the goods arrived the destination port.
4.If you have any question, please contact us freely. Our after-sales service team on line ,we will do the best
to accomplish your sincere requirement on time.
