Stainless Steel Packing Food Machinery / Packing Machinery
packing machine introduction
1. Dual frequency conversion control, bag length can be set and cut on one step, saving time and film.
2 . Interface features easy and quick setting and operation.
3 . Self failure diagnosis, clear failure display.
4 . High sensitivity photoelectric eye color tracing, numerical input of cutting sealing
position for extra accuracy.
packing machine specification
|
1 . Temperature independent PID control, more suitable for packing different materials. |
|
2 . Positioned stop function, without sticking knife or wasting film. |
|
3. Simple driving system, reliable working, convenient maintenance. |
packing machine feature
1 . Simple operation , Easy maintenance
2 . Durable
3 . Efficient follow-up service
4 . easy for function adjusting and technical upgrade.
5 . Temperature independent PID control
6 . Positioned stop function
7 . All control is realized through software,
packing machine applications
Food: biscuit ,flier rice cake, cake, chocolate,bread, instant noodle, moon cake , or with tray product etc regular shape
Others. Medicine , tape, electric switch , etc regular shape
packing machine parameter
Type |
350B |
350D |
Film Width |
Max.350mm |
|
Bag length |
120-190mm |
150-220mm |
Bag width |
50-160mm |
|
Product height |
Max.45mm |
Max. 60mm |
Film roll diameter |
Max.320mm |
|
Packing speed |
40-230 bag/min |
|
Power |
220V,50/60HZ,2.6KVA |
|
Machine size |
(L)4020×(W)745×(H)1450 |
|
Machine weight |
900Kg |
|
packing sample
Related food packing machine products
Type |
250X |
350X |
Film Width |
Max.250mm |
Max.350mm |
Bag length |
65-280mm |
65-280mm |
Bag width |
30-110mm |
50-160mm |
Product height |
Max.40mm |
Max.45mm |
Film roll diameter |
Max.320mm |
Max.320mm |
Packing speed |
40-230 bags/min |
40-230 bags/min |
Power |
220V,50/60HZ,2.4KVA |
220V,50/60HZ,2.8KVA |
Machine size |
(L)3920×(W)670×(H)1320 |
(L)4020×(W)720×(H)1320 |
Machine weight |
650Kg |
700Kg |
Type |
450 |
Film Width |
Max. 450mm |
Bag length |
130-450mm |
Bag width |
50-180mm |
Product height |
Max.70mm |
Film roll diameter |
Max. 320mm |
Packing speed |
30-180bag/min |
Power |
220V,50/60HZ,2.6KVA |
Machine size |
(L)4020×(W)820×(H)1450 |
Machine weight |
900Kg |
Payment terms
T/T , L/C ,Western Union , Moneygram ,etc .
