YHZS50 mobile concrete mixing plant for sale
YHZS series of mobile concrete mixing plant is a new type of trailerable mobile concrete mixing plant. It is your best choice for mobile operations in various constructions such as highway, railway, architecture, municipal engineering, bridge, port and hydropower station.
Features of the YHZS50 concrete mixing plant
- Easy installation and start-up
- Fully automatic robust control system
- Technologic and high quality production
- Less installation area requirement with compact design
- Less foundation costs (%80 less than stationary concrete batching plants
- No requirements for local authorizations for the installation
- Less maintenance and operating costs
-
Less transportation costs
Parameter of the YHZS50 concrete mixing plant
YHZS50 | ||
The whole introduction |
capacity |
50m³/h |
mixing time |
60s |
|
max aggregate size |
60/80mm |
|
discharging height |
3800mm |
|
total power |
105kw |
|
Mixing system |
mixer model |
JS1000 |
capacity |
1000L |
|
input capacity |
1600L |
|
dimensions |
4640*2250*3385mm |
|
Batching machine |
Model |
HPD1600 |
volume |
3*6m³ |
|
capacity |
60m³/h |
|
power |
5.5kw |
|
lifting hopper |
3 units |
|
lifting speed |
1.5m/s |
|
power of motor |
11kw |
|
Cement system(optional) |
cement silo |
100T*3 |
cement screw feeder |
3 units |
|
length |
9m |
|
Water system |
motor power |
6kw |
capacity |
150m³/h |
|
Additive system(optional) |
additive capacity |
3m³ |
pump power |
3kw |
|
Note: The above technical parameters are just for your reference.
Cercification of the YHZS50 concrete mixing plant
Any question about concrete mixing plant for sale,please feel free to let us know.
Contact person: Alisa Wang
Email: alisa#
Mob: +86-15638416296
Skype: 70
