UCFL208 Pillow Block Rotating Bearing

UCFL208 Pillow Block Rotating Bearing thumbnail-1
UCFL208 Pillow Block Rotating Bearing photo-1
US$ 0.5 - 300 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Bore Size:
5, 300
Brand Name:
HHZC
Model Number:
UCFL208
Contact Supplier Request Quote Chat Now
Nantong Haihui Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Bore Size 5, 300
Brand Name HHZC
Model Number UCFL208
Place of Origin Jiangsu, China

Pillow block bearing is a kind of bearing that looks like a small ball bearing that has a casting pedestal or a pressed steel plate and a double seal. If you will look closely inside it, you will see that the pillow block bearings is very much the same as the other kinds of bearing like the deep groove ball bearings. The only difference is that is you will look closely at the outer ring of the pillow block bearings, you can see that it has section balls which is best use with the concave part of the bearing pedestal.



Pillow blocks are usually mounted in cleaner environments & generally are meant for lesser loads of general industry. These differ from "plummer blocks" which are bearing housings supplied without any bearings & are usually meant for higher load ratings & corrosive industrial environments. However the terms pillow-block & plummer-block are used interchangeably in certain parts of the world



Product information:



                                                      UCFL208 pillow block rotating bearing

Bearing
No.		 Dimensions  mm
inch		 Bolt Size
mm
inch
d a e i g l s b z B n
UCFL201
UCFL201-8		 12
1/2		 113
4-7/16		 90
3-35/64		 15
19/32		 11
7/16		 25.5
1		 12
15/32		 60
2-3/8		 33.3
1-5/16		 31
1.2205		 12.7
0.500		 M10
3/8
UCFL202
UCFL202-9
UCFL202-10		 15
9/16
5/8		 113
4-7/16		 90
3-35/64		 15
19/32		 11
7/16		 25.5
1		 12
15/32		 60
2-3/8		 33.3
1-5/16		 31
1.2205		 12.7
0.500		 M10
3/8
UCFL203
UCFL203-11		 17
11/16		 113
4-7/16		 90
3-35/64		 15
19/32		 11
7/16		 25.5
1		 12
15/32		 60
2-3/8		 33.3
1-5/16		 31
1.2205		 12.7
0.500		 M10
3/8
UCFL204
UCFL204-12		 20
3/4		 113
4-7/16		 90
3-35/64		 15
19/32		 11
7/16		 25.5
1		 12
15/32		 60
2-3/8		 33.3
1-5/16		 31
1.2205		 12.7
0.500		 M10
3/8
UCFL205
UCFL205-13
UCFL205-14
UCFL205-15
UCFL205-16		 25
13/16
7/8
15/16
1		 130
5-1/8		 99
3-57/64		 16
5/8		 13
1/2		 27
1-1/16		 16
5/8		 68
2-11/16		 35.8
1-13/32		 34.1
1.3425		 14.3
0.563		 M14
1/2
UCFL206
UCFL206-17
UCFL206-18
UCFL206-19
UCFL206-20		 30
1-1/16
1-1/8
1-3/16
1-1/4		 148
5-13/16		 117
4-39/64		 18
45/64		 13
1/2		 31
1-7/32		 16
5/8		 80
3-5/32		 40.2
1-19/32		 38.1
1.5000		 15.9
0.626		 M14
1/2
UCFL207
UCFL207-20
UCFL207-21
UCFL207-22
UCFL207-23		 35
1-1/4
1-5/16
1-3/8
1-7/16		 161
6-11/32		 130
5-1/8		 19
3/4		 14
35/64		 34
1-13/32		 16
5/8		 90
3-35/64		 44.4
1-3/4		 42.9
1.6890		 17.5
0.689		 M14
1/2
UCFL208
UCFL208-24
UCFL208-25		 40
1-1/2
1-9/16		 175
6-7/8		 144
5-43/64		 21
53/64		 14
35/64		 36
1-13/32		 16
5/8		 100
3-15/16		 51.2
2-1/64		 49.2
1.9370		 19
0.748		 M14
1/2
UCFL209
UCFL209-26
UCFL209-27
UCFL209-28		 45
1-5/8
1-11/16
1-3/4		 188
7-13/32		 148
5-53/64		 22
55/64		 15
19/32		 38
1-1/2		 19
3/4		 108
4-1/4		 52.2
2-1/16		 49.2
1.9370		 19
0.748		 M16
5/8
UCFL210
UCFL210-29
UCFL210-30
UCFL210-31
UCFL210-32		 50
1-13/16
1-7/8
1-15/16
2		 197
7-3/4		 157
6-3/16		 22
55/64		 15
19/32		 40
1-37/64		 19
3/4		 115
4-17/32		 54.6
2-5/32		 51.6
2.0315		 19
0.748		 M16
5/8
UCFL211
UCFL211-32
UCFL211-33
UCFL211-34
UCFL211-35		 55
2
2-1/16
2-1/8
2-3/16		 224
8-13/16		 184
7-1/4		 25
63/64		 18
23/32		 43
1-11/16		 19
3/4		 130
5-1/8		 58.4
2-5/16		 55.6
2.1890		 22.2
0.874		 M16
5/8
UCFL212
UCFL212-36
UCFL212-37
UCFL212-38
UCFL212-39		 60
2-1/4
2-5/16
2-3/8
2-7/16		 250
9-27/32		 202
7-61/64		 29
1-9/64		 18
23/32		 48
1-7/8		 23
29/32		 140
5-1/2		 68.7
2-23/32		 65.1
2.5630		 25.4
1.000		 M20
3/4
UCFL213
UCFL213-40
UCFL213-41		 65
2-1/2
2-9/16		 258
10-5/32		 210
8-17/64		 30
1-3/16		 22
7/8		 50
1-31/32		 23
29/32		 155
6-3/32		 69.7
2-3/4		 65.1
2.5630		 25.4
1.000		 M20
3/4
UCFL214
UCFL214-42
UCFL214-43
UCFL214-44		 70
2-5/8
2-11/16
2-3/4		 265
10-7/16		 216
8-1/2		 31
1-7/32		 22
7/8		 54
2-1/8		 23
29/32		 160
6-5/16		 75.4
2-31/32		 74.6
2.9370		 30.2
1.189		 M20
3/4
UCFL215
UCFL215-45
UCFL215-46
UCFL215-47
UCFL215-48		 75
2-13/16
2-7/8
2-15/16
3		 275
10-13/16		 225
8-55/64		 34
1-11/32		 22
7/8		 56
2-7/32		 23
29/32		 165
6-1/2		 78.5
3-3/32		 77.8
3.0630		 33.3
1.311		 M20
3/4
UCFL216
UCFL216-49
UCFL216-50
UCFL216-51		 80
3-1/16
3-1/8
3-1/16		 290
11-13/32		 233
9-11/64		 34
1-11/32		 22
7/8		 58
2-9/32		 25
63/64		 180
7-3/32		 83.3
3-9/32		 82.6
3.2520		 33.3
1.311		 M22
7/8
UCFL217
UCFL217-52
UCFL217-53
UCFL217-55		 85
3-1/4
3-5/16
3-7/16		 305
12		 248
9-49/64		 36
1-27/64		 24
15/16		 63
2-15/32		 25
63/64		 190
7-15/32		 87.6
3-7/16		 85.7
3.3740		 34.1
1.343		 M22
7/8
UCFL218
UCFL218-56		 90
3-1/2		 320
12-19/32		 265
10-7/16		 40
1-37/64		 24
15/16		 68
2-11/16		 25
63/64		 205
8-1/16		 96.3
3-25/32		 96
3.7795		 39.7
1.5630		 M22
7/8





Work Shop:

UCFL208 pillow block rotating bearingUCFL208 pillow block rotating bearingUCFL208 pillow block rotating bearing



Canton Fair Show:

UCFL208 pillow block rotating bearing
