Welcome to our wite,
Best service will be offered for you
1. Basic Functions
a) Screening
Screening is to divide solid particles into different particle groups of various sizes. This rotary vibration filter sieve configured with one to five screening nets is able to accurately and continuously separate two to six particle sections with
its classification accuracy up to 95%.
b) Screening out impurities
High-precision screening net, mostly single-used, can remove those lower percentages of large or small particles quickly
in the process of high-flow material handling. The advanced design of vibration filter sieve make it decontaminate the material efficiently and with high quality. Its precision can reach up to 98%.
c) Slurry filtration
Three-D vibration, high-precision screening net, mostly single-used, can rapidly remove non-soluble granular materials from slurry.
2. Introduction
China multi-layer vibratory separator machine is used for sorting automatically powders and solid material in general.
Seven years of modifications and technical updates, the wide range available, the accessories and reliability make the
machine is well received in home and aboard.
3. Advantages
1. High screening accuracy and efficiency, applicable to any categories of flour, particle and mucus.
2. No dead angle, easy to clean and disinfect thoroughly.
3. New-fashioned network structure, long life span and only 3 to 5 minutes needed to change it.
4. Used either with single screen or multi-screens.
5. Light and handy in volume, convenient to move and adjustable to any angle.
6. Material to be discharged automatically, and able to operate continuously.
7. Totally enclosed, no dust flying, no liquid leaking, no mesh blocked.
Screening accuracy can reach to 500 mesh particle size.
4. Specifictions
7 standard models can be offered to meet your different capacities,
Model |
Diameter |
Screen surface |
Screen opening |
Power |
Deck |
|
(mm) |
Diameter |
Area |
(kw) |
|||
(mm) |
(m2) |
|||||
HY-400 |
400 |
360 |
0.1017 |
5-500 mesh |
0.18 |
1-4 |
HY-600 |
600 |
560 |
0.2461 |
0.25-0.55 |
1-4 |
|
HY-800 |
800 |
760 |
0.4534 |
0.55-0.75 |
1-4 |
|
HY-1000 |
1000 |
930 |
0.6789 |
0.75-1.5 |
1-4 |
|
HY-1200 |
1200 |
1130 |
1.0023 |
1.10-1.75 |
1-4 |
|
HY-1500 |
1500 |
1430 |
1.6052 |
1.50-2.20 |
1-4 |
|
HY-1800 |
1800 |
1730 |
2.3494 |
2.20-3.0 |
1-4 |
|
5. Different types of our vibratory separator,
Tell us three questions, best models machine offered for you,
1. The specific name of your material?
2. The wire screen mesh sizes you needed??
3. The production capacity per hour you wanted??
Write e-mail to us now, we are always in service for you!
