farm machinery parts E300 Clutch Assembly
- 20000 Set / Sets per Month
- NINGBO
- T/T Credit Card PayPal
Product Details
Type: | Other, clutch assembly, Independent Dual Stage | Use: | Tractors | Place of Origin: | Zhejiang, China |
Brand Name: | OEM | Model Number: | E300 Clutch Assembly |
Packaging Details
follow the market rules and combine with your requirement
Product Description
Specifications
1.E300 Clutch Assembly is widely used for tractor 30-35 hp.
2.High friction coefficient,low fading and stable performance.
Model | E300 Clutch Assembly |
Type of Clutch | Independent Dual Stage |
Outer/Inner Diameter of Friction Plate(mm) | φ228×φ146(Major) |
φ228×φ146(Subsidiary) | |
Number of Friction Surfaces | 2 |
Friction Materials | non asbestos(Major) |
non asbestos(Subsidiary) | |
Dimension of Spline(number of teeth×modulus/spline width) | 18×2 |
6×5 | |
Work Compressing Force | 4500-5000 |
Compressing Method | Disk Spring |
Connection Dimension | 6-φ11holes in uniform distribution on φ336 diameter,φ362h8 seam allowanceor 2-φ10 locating pin |
Model of Assembling Tractor | 30-35 horsepower |
