60Cu.M mobile concrete plant for sale with fully-automatic control system
Mobile concrete plant for sale is widely used for construction projects' concrete mixing, the concrete mixer is new designed spiral compound blades concrete mixer, the aggregate supply is with belt conveyor, the aggregate batching system can be 2 bins or 4 bins, with auto weighting, fully auto-control with SIEMENS brand PLC.
The mobile concrete plant for sale are widely sale in Philippines, South Africa, Russia, Australia, Greece, Sri Lanka and etc. countries.
Specification of YHZS60 mobile concrete plant for sale
|
Main Parameter |
Model |
YHZS60 |
Capacity |
50-60m3/h |
|
Dimension |
Working: 17.7*3.6*8.2m |
|
Transport: 18.3*2.4*4.35m | ||
Discharging Height |
3800m |
|
Max Drag Speed |
40km/h |
|
Total weight |
about 25t |
|
Installed Power |
about 70Kw |
|
|
Concrete Mixer |
Model |
JS1000 |
Capacity |
50m3/h-60m3/h |
|
Charging Volume |
1600L |
|
Discharging Volume |
1000L |
|
Motor Power |
2*18.5 Kw |
|
Aggregate Dameter |
60-80mm |
|
Aggregate Batcher |
Model |
PLD1600 |
Capacity |
≥80m3/h |
|
Storage Silo No. |
4 |
|
Storage Silo Volume |
6m3 |
|
Max. Measuring Capacity |
4000kg |
|
Batching Precision |
±2% |
|
Belt Conveyor |
Belt conveyor Angle |
26° |
Belt Width |
650mm |
|
Belt Power |
11kw |
|
Weighting System |
Sandstone Precision |
4000kg±2% |
Cement Precision |
720kg±1% |
|
Water Precision |
360kg±1% |
|
Additive Precision |
36kg±1% |
|
Air System |
Air Compressor |
4Kw |
Rated pressure |
1.0 Mpa |
|
Volume of emission |
0.7m3/min |
|
Volume of emission |
0.32m3/h |
|
|
Screw Conveyor Optional |
Model |
LSY219 |
Capacity |
25t/h |
|
Diameter |
219mm |
|
Power |
10kw |
|
Length |
8m |
|
|
Cement Silo Optional |
Capacity |
100T |
Arch breaking device |
V2FS250GBN |
|
Dust Wiper |
1set |
|
Level measure device |
VFS |
For the mobile concrete plant for sale:
Packaging: standard package for exporting
Shipping:usually 3 pcs 40HQ containers are needed, without optional parts.
1. 12months waranty for the mobile concrete plant for sale.
2. Engineer can be assigned to guide installation and commission for the mobile concrete plant for sale.
3. After-sales engineers are available for 24hours/7days.
4. Spares parts are always in stock.
UNIQUE is a professional construction machinery manufacturer for over 30 years, with exporting the machines to over 60 countries and areas within the past 10 years, products include concrete mixer, stationary concrete batching plant, mobile concrete plant for sale, cocnrete truck mixer, cocnrete pump, concrete block making machine and etc.
