Specifications
1. Accurate weighing batcher machine,2. High quality, ISO certification,
3. High precision batching,
4. Quick speed.
Descriptions of PLD Series Aggregate batcher Machine:
“PLD” in PLD2400-3 is given by Chinese government that all of the Concrete Batching machine must use this Series Number.
“2400” in PLD2400-3 stands for the capacity of the weighing hopper is "2400 liter"
“3” in PLD2400-3 stands for number of the storage hopper is 3.
Function of Concrete Batcher :
PLD series concrete batching machine can automatically finishing the batching procedures of 3-6 kinds of materials such as sand, stone, cement according to users requirement. These serial products adopt electronic weighing, computer control, digital display, wired remote control operation.Use this serial concrete batching machine +Unique concrete mixer, with the computer control system batching sand macadam and other materials automatic, you can produce any formulation concrete as the project requested .
The block or concrete manufacturer can also realize substantial savings by using less sand and stone to produce the high quality product.
Number and volume of hopper can design and produce according the concrete request.
This series batching machine adopted the accumulation weighing , the weighing accuracy is ±2%.
This series batching machine can be equipped with an automatic control or wired remote for loading aggregate into skip hopper.
PLD800-3 Model Specification
Item |
Unit |
PLD 2400-3 |
PLD 3200-4 |
PLD 4800-4 |
Scale hopper volume |
Liter |
2400 |
3200 |
4800 |
Storage hopper volume |
m3 |
3×12 |
4×20 |
4×25 |
Productivity |
m3/h |
≥120 |
≥160 |
≥280 |
Batching precision |
|
±2% |
±2% |
±2% |
Max weighting |
kg |
4000 |
5000 |
8000 |
Aggregate number |
|
3 |
4 |
4 |
Feeding height |
mm |
3500 |
3500 |
3800 |
General power |
kW |
11 |
11 |
15 |
Weight |
kg |
8500 |
10200 |
13600 |
Dimension (L*W*H) |
mm |
9800×2800×3900 |
13500×2900×4450 |
15900×3900×5000 |
Division value checking |
kg |
2.0 |
2.0 |
2.0 |
Optional Structure character |
The feeding structure is arranged in line, charging through the belt, and the measuring system is a single sensor and lever. |
|||
Advantages Of PLD Series Aggregate batcher Machine:
1. Perfect humanization Electrical control system
Siemens PLC or remote control operation system provide you a accredited operation machine.
2. Load Cell :
It guarantees the precise of the aggregate and protects the products from transfiguration.
3. Discharging System. Make in China, world Quality, and we can provide you the rubber belt as you request .
4. Compulsory Feeding system make sure that the density and intensity of the products are guaranteed;
