UT90HP 4wd chinese agricultural machinery

Specifications

UT90HP 4wd chinese agricultural machinery:
1. Engine Rated Power: 70HP
2. YTO or Yuchai Engine
3. 4WD
4. CE Certificate

 UT90HP 4wd chinese agricultural machinery



Features of our UT 904 chinese agricultural machinery

1. Be adopted brand engine, large reserve power, low oil consumption, good economic performance, and high in reliability.

2. Hydraulic steering combination meters and combination switch are both good to look and easy to operate.

3. Besides independent double-speed power output, the synchronizing power output is set up; 540, 720, 1000 are optional for the customers. chinese agricultural machinery

4. The raiser is equipped with auxiliary oil cylinder, and the raising force is 22kn-25kn, and able to lift various large-scale composite farm implements, and realize the plowing operation by four depth-adjusting modes-force adjustment, position adjustment, force and position adjustment and floating adjustment.

5. Full-closed streamline luxury driving cab, adjustable spring seat, cold or warm air conditioner and complete sound equipment, comfortable driving environment; chinese agricultural machinery

6. Be equipped with multi-piece three-position multi-channel valve, also can be equipped with former loading and latter excavation and other engineering tools. chinese agricultural machinery



Main Specifications of chinese agricultural machinery

Model	UT804	UT854	UT904	UT954
Drive type	4x4	4x4	4x4	4x4
Overal size(LxWxH)mm	4593 x2050 x2810
Wheel base(mm)	2193.5	2193.5	2193.5	2193.5
Mininum ground  clearance(mm)	389	389	389	389
Front tire	11.2-24
Rear tire	16.9-34
Engine
Engine Model	LRC4108T77-1	LR4B3Z-77-A	LR4MC-77-1	LR4B3Z-T-85
Type of engine	Vertical,direct injection,water cooled, 4 cylinder,4 Stroke diesel engine
Capacity of fuel tank(L)	150L	150L	150L	150L
Engine power	59KW	62.5KW	66.2KW	70KW
PTO power at rated speed	2300	2400	2300	2300
Clutch	Dry,dual stage type
PTO speed	540/1000,( 760/1000 optional)
Gear shift	8F+4R /16F+8R(Optional)/8F+8R (Optional)
Hydraulic output valve	Mulit-way Valve (optional)
Category of 3-point link	II	II	II	II
Lifting force(at point of 610mm)KN	19.5	19.5	19.5	20.1
Speed (Km/h)	2.31-34.85



Zhengzhou Unique Industrial Equipment Co.,Ltd. is professional China wheeled tractor supplier. We can offer you all typs of agriculture tractors 18~130hp. If you are interested in our products, please contact us directly or email us. To quote the tractor price, please kindly inform us followings: 1. what is the power of the wheel tractor? 2. with or without tractor cab? 3. about how many units? 4. need the new tractors to be with any certificated for your market? We are certain that you will be satisfied with your purchase.
