Home > Products > oil press and complete oil equipment > TXP160 dry extruder for soybean or rice bran
TXP160 dry extruder for soybean or rice bran
- 200 Set / Sets per Month
- qingdao tianjin
- T/T Credit Card
Product Details
Type: | farm machine | Use: | soybean or rice bran oil processing | Certification: | CE |
Place of Origin: | Henan, China | Brand Name: | HYPH | Model Number: | TXP165 |
Condition: | New |
Product Description
Specifications
The machine combines feeding,heating,extruding and shaping,essential equipment for the production of rice bran and soybean oil.The machine combines feeding,heating,extruding and shaping,it has below features: advanced process,compact volume,smooth running,low noise,high production efficiency,easy operation,convenient maintenance,etc.The quality is international accepted,so is essential equipment for the production of rice bran oil and soybean extruding for oil.
Working principle
By the squeezing and shearing forces of unequal-pitch pressing screw worms, the mechanical energy is converted into heat energy,heat the material inside to approx,then shaped.
Main functions:
1. The extruding of rice bran
1.1 After experiment,rice bran processed by this machine,compared with unprocessed material,the acid value down approx.3mgKOH/H oil,the water content down approx 3%.
1.2 Fresh keeping:the acid value of processed rice bran raise about 1mgKOH/g after a month,even at high-temperature season,after 3-6 months storage,the rice bran still fulfills for the oil production standard.On the contrary,the acid value of unprocessed rice bran will raise approx 46mgKOH/g oil in only one week, so the value for oil production completely lose.
1.3 The diameter of processed rice bran is approx dia3-5mm,helps the permeate of solvent liquid,and get best effect of extraction.By actual production results,compared with traditional oil pressing production process,the extraction process can double the oil yield,and help the refining rate by approa.20% up,the extracted defatted rice bran is the best material for the production of inositol and also ideal feed ingredient.
1.4 The processed rice bran can produce high quality salad oil.
2. The extruding of soybean
The machine also can be used for expanding soybean.Use the machine to expand soybean can replace the traditional flaking,prepressing process.The direct extraction of soybean has below features:
2.1 The production capacity of extraction can raise by 40-50%.
2.2 At the same extraction condition,the residue oil rate of meal is lower.
2.3 The solvent content in wet meal is lower 20% than direct extraction of soybean flakes.
2.4 The total power and steam consumption and maintenance cost of equipment reduced.
Technical data for TXP160 dry extruder
1 Capacity:800~1000kg/h for soybean
2 Main speed:630r/min
3 Feeding speed: 200~400r/min
4 Main power:55kw
5 Feeding power: 2.2kw
6 Electricity consumption:<45kw·h/t
7 Noise:<80dB(A)
8 Process temperature: 80~140degree
9 Dimension:2150×2100×1280mm
10 Whole weight:1800kg
