2013 Electric Roaster Machine 0086 15038228936

2013 Electric Roaster Machine 0086 15038228936 photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other, roasting the oil seeds and nuts
Type:
Other, Seed Roaster, stainless steel nuts and oilseeds drying machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Usage Other, roasting the oil seeds and nuts
Type Other, Seed Roaster, stainless steel nuts and oilseeds drying machine
Automatic Grade Automatic
Production Capacity 100-300kg/h
Place of Origin Henan, China
Brand Name Holyphant
Model Number MHK
Voltage 380V
Power(W) 1.1-2.2kw
Dimension(L*W*H) 2900*14001700mm 2900*2200*1700mm
Weight 700-1400kg
Certification CE ISO
After-sales Service Provided Overseas third-party support available

Specifications

1. suit for peanut, sesame, cashew, almond nuts etc.
2. Own factory, low price
3. CE ISO9001
4. 200-300kg/h
Stainless steel





Application and working principle:



Roaster machine mainly used for roasted peanuts, peanut, peanut, walnut, chestnut, almond, swallow beans, coffee beans, sesame, seeds and other granular nuts food. This machine with electric as heat source, the use of conduction of heat radiation principle baking material ;  materials doesn't contact with fireworks when baking, During the baking process material in the drum within the spiral sheet continuously push, form continuous rolling, is heated evenly, effective guarantee the baking quality, color, taste.





Structure and performance:



Composed by the hopper, a out hopper, frame body, thermal insulation layer, internal cylinder body, motor and reducer chain, transmission assembly, electrical cabinet.



Positive rotation roasted, reverse rotary discharge.Heating assembly thermostatic control: normal temperature -300 degrees.





Main Data:



Internal cylinder body,:Stainless steel sieve 3mm

Chain Wheel:6min(19.05) 28tooth  14tooth

Chain:6min(19.05)

Reduction motor:2.2KW

Machine body:carbon steel

One set electrical control cabinet assembly

Bearing pedestal:1511,1510

Bearing:6308,6309





Note: Fuel can be electric, gas, coal and wood.





Model:MHK--1 (the contact part with the raw material is stainless steel)



Capacity:100kg/h



Size:2900*1400*1700



Temperature: 300°C(automatic constant temperature)



Power: 1.1kw  Heating power 18kw



Voltage:380V(50hz)


Weight: 700KG







Model:MHK--2 (the contact part with the raw material is stainless steel)



Capacity:200--300kg/h



Size:2900*2200*1700



Temperature: 300°C(automatic constant temperature)



Power: 2.2kw / the heating power:40kw



Voltage:380V(50hz)





Weight: 1400KG





 Detail Pictures:



 2013 electric roaster machine 0086 150382289362013 electric roaster machine 0086 150382289362013 electric roaster machine 0086 150382289362013 electric roaster machine 0086 15038228936







2013 electric roaster machine 0086 15038228936





Any more question and advice, pls call TEL:0086 15038228936 !!! I'm waiting for you.





2013 electric roaster machine 0086 15038228936
