Oilless Slidng Series:
Cast Bronze Bearing,auto bearing bushing /high hardness bushing
We always focus on quality as you are .....
#500 SP-1 Buried Solid Lubricating Bushing:
-----------------------------------------------------------------------------------------------------
Cast Bronze Bearing has a backing made of bronze with particular formulation supported by certain angle and density and produced with advanced casting techniques. The solid lubricating material inlaid in the bushing is compounded in a unique way. #500 is used in succesive casting machines, steel rollers in metallography, mineral machines, ship, turbogenerators, hydraulic turbines and injection molding machines for plastics, machine hand and the oil platform on sea, etc.
Performance |
Data |
Material Composition |
Cast Bronze |
Hardness HB |
>210 |
Tensile Strength |
>750 |
Elongation % |
>12 |
Limit Temp. |
300 |
Max. Load |
100 |
Max. Speed m/min |
15 |
Max. PV (Dry) |
200 |
Other #500 Series Bushing:
#500 SP-2 Buried Solid Lubricating Bushing
Performance |
Data |
Material Composition |
Cast Bronze |
Hardness HB |
>180 |
Tensile Strength |
>550 |
Elongation % |
>12 |
Limit Temp. |
300 |
Max. Load |
80 |
Max. Speed m/min |
15 |
Max. PV (Dry) |
200 |
#500 SP-3 Buried Solid Lubricating Bushing
Performance |
Data |
Material Composition |
Strong Cast Bronze |
Hardness HB |
>250 |
Tensile Strength |
>800 |
Elongation % |
>4 |
Limit Temp. |
300 |
Max. Load |
150 |
Max. Speed m/min |
10 |
Max. PV (Dry) |
200 |
#500 B-1 Buried Solid Lubricating Bushing
Performance |
Data |
Material Composition |
Copper Alloy |
Hardness HB |
>70 |
Tensile Strength |
>200 |
Elongation % |
>15 |
Limit Temp. |
400 |
Max. Load |
60 |
Max. Speed m/min |
10 |
Max. PV (Dry) |
200 |
Facility Overview:
Please contact DALON for more types......
DALON MACHINERY CO.,LIMITED
Top Choice of Industrual solution......
