Made in China Saw dust briquette machine and biomass wood briquette making machine
I. Main technical data of sawdust briquette machine
Type |
End Diameter of briquette |
Motor |
Capacity |
Inlet raw diameter |
Machine Dimension |
ZBJ15 |
50 |
15kw |
180-200kg/h |
≤5mm |
1.7×0.66×1.5m |
ZBJ18.5 |
50/70/80 |
18.5kw |
200-250kg/h |
≤5mm |
1.75×0.66×1.5m |
ZBJ22 |
50/70/80 |
22kw |
250-400kg/h |
≤5mm |
1.78×0.66×1.53m |
II The usage of sawdust briquette machine
Sawdust briquettes machine are widely used in biomass power plant heating industry ,boiler heat source and other industries .
III The advantage of sawdust briquette machine
1.No need binder
2.Good quality propeller
3.No smoking
4. high density briquettes
4. Supply complete production line
IV. Working Principle of sawdust briquette machine
Under the high temperature and high pressure, the natural lginin in biomass will be liberated with wood fiber, it will serve us glue function, the front of propeller and the back of mold will produce the high pressure to the raw materials, the heating ring produce the heat for the briquettes
V. Internal structure and spare parts
1. Electric control board
2. 18.5kw Motor
3. Under Hopper
4. Body
5. Body
6. Propeller
7. Wear sets
8. Forming Cones
VI.The raw material of sawdust briquettes machine
Wood chips, maize stalks, soybean stalks, broomcorn stalks, cotton stalks, rape stalks,peanut plants, sunflower stalks, bamboo saw dust, etc.
VII.The process for producing charcoal briquette as follow:
(1). Crush the raw material into small pieces (diameter is about 3-6mm)
(2). Dry the material by machine or dried it in the sun , till the moisture is less than 14%
(3). Put the material into feed let of briquette machine
(4). Produce the briquette stick from biomass material without any additive
(5). Carbonized the briquette stick
Company Information
Jingying Machinery Manufacturing factory,
being established in 1986, works on designing
and manufacturing complete set of energy
saving machines and recycling equipment.
Our top selling recycling machines are full
auto wood pellet machine,charcoal and coal
briquetting machine, metal shredders,
industry crushers and brick producing
Machines.
Welcome you to visit our factory!
FAQ
1. what is shape and diameter of final product?
Hexagon is the most popular, the diameter is 50mm.
2. What is screw gap of propeller?
The screw gap could be the size as 32mm,36mm,40mm. (36mm is the most common )
3. What is the real load of heating ring?
ZBJ-1 1.5kw*3
ZBJ-2 2.2kw*3
ZBJ-3 3kw*3
