Edible Oil Refinery Plant /crude Oil Refinery Machine Manufacturer Newest Oil Refinery Equipment

Basic process of   Refine oil machine

 Introduction of Refine oil machine

1. The  oil refining machine is used for removing the impurities of oil, such as, fatty acid, phosphatide, metal ion, pigment, oxide, solid particle and volatile gas. It suitable for refining various crude oil,  such as sunflower seed oil, vegetable oil , peanut oil, tea seed oil, groundnut oil, mustard seed oil ,cottonseed oil, rice bran oil, soybean oil, corn germ oil and palm oil,etc.

2. The oil  refining machine can adopts chemical refining and physical refining, and the chemical refining includes batch refining, semi-continuous refining and continuous refining.

1. The decolour tank is for bleaching grease.

2. The deodorizing tank is for desdorizing grease(stainless steel).

3. The conducting oil furnace provide thermal enery need for production,

    the temperature reach to 280degree.

4. The vacuum pump provides vacuum for bleaching.

    deodorization which can reach 755mmHg or more;

5. The Air compreassor can dry the bleached clay

6. The air press is for filter clay

7. The steam generator can generate steam distillation required.

8. This kind of oil refining eqiupment make the oi reach the standard level national

    edible oil.

1. Advanced oil extraction tech.; simplified structure of the same type of extractor.

2. Replaced with a false bottom plate fixed grid, reducing the movement mechanism, high safe

operation rate, work reliably.

3. With a self-cleaning effect, clean up grid plate without downtime.

4. It can increase the leaching time of the material, reduce meal residual rate.

5. It can increase the loading factor, increase production.

Name

Model

Production

power

size

function

Refining machine

TZ-50WD

500KG/8H

5KW

1500*680*1400

Degumming, dephosphorylation, bleaching

Refining machine

TZ-75WD

1000KG/8H

7KW

1800*800*1400

Degumming, dephosphorylation, bleaching

Refining machine

TZ-100WD

1400KG/8H

9KW

2200*1000*1500

Degumming, dephosphorylation, bleaching
