Specifications
coil nail making machine:1.easy to operate and maintain
2.low noise,energy saved
3.high speed, best price.
4.CE.ISO9001.etc
factory supply coil nail making machine
Description of coil nail making machine:
1.The coil nail making machine adopts piston structure to ensure the high working speed, low noise, high size accurancy and less chance of impact characteristics.
2.The coil nail making machine can make excellent quality nail and other special-shaped nail which are suitable for high speed studs for welding machine and nail gun.
3.The coil nail making machine has the features of high speed, low noise, less impact and good continuity.
Features of coil nail making machine:
1. This coil nail making machine can feed the materials automatically.
2 .This coil nail making machine has the features of high speed, low noise, less impact.
3. All the main components are made of quality steel, such as shaft, cams and gear.
4. The nails will be straight, the point of the nails will be sharp and symmetrical, the nails cap will be round, every nail will be perfect.
Main Teachincal parameters of coil nail making machine:
Model | Diameter | Length | Output | Power | Dimension(mm) | Weight |
FR-NM-1.6 | 0.9-1.6mm | 9-25mm | 460 pcs/min | 1.5kw | 1500×1300×1200 | 1200kg |
FR-NM-12 | 1.2-2.8mm | 16-50mm | 320pcs/min | 2.2kw | 1700×1300×1400 | 1450kg |
FR-NM-13 | 1.8-3.1mm | 30-75mm | 300pcs/min | 3kw | 2000×1400×1400 | 1800kg |
FR-NM-14 | 2.8-4.5mm | 50-100mm | 280pcs/min | 4kw | 2200×1600×1650 | 2000kg |
FR-NM-5 | 3.7-5.0mm | 90-125mm | 210pcs/min | 4kw | 2630*1700*1750 | 2900kg |
FR-NM-6 | 4.5-6.0mm | 100-180mm | 160pcs/min | 11kw | 3000*1850*1750 | 5000kg |
Process line of coil nail making machine:
A)wire drawing machine---to make the diameter of material to the diameter of the nails you want.
B)coil nail making machine--- to make nails
C)polishing machine--- to polish the nails finished
D)knife grinder--- to grind the knives of coil nail making machine
Material of nails is the wire rods with diameter less than 8mm and length more than 10cm.
Shipments for coil nail making machine:
If you are interested in our coil nail making machine, plese feel free to send us an enquiry!!!!!
Send Inquiry to This Supplier
