High production capacity charcoal dust briquette machine
Product description
Honeycomb briquette machine normally called briquette machine. The raw material is coal that passed treatment, through the mixing and pressing into a honeycomb shape. This briquette machine convenient to exchange mold, can produce many different standards. Moreover, it also can exchange many different shapes, such as a cylindrical, box shaped briquettes. This is way greatly expand the functions of honeycomb briquette machine. It can be regarded as ideal briquette machine products for entrepreneurial.
In the early years, the coal briquette mainly used for a family to make a fire and warm because of the single shapes. At present, the briquette machine has been through several improvements to achieve matured technology. It can make briquette with most utility shapes and standards. This way can increase the surface area of coal to sufficiently burning and reduce resource waste. Nowadays, the final product can be used as barbecue charcoal, cooking, heating, fuel, boiler, etc.
Machine structure and principle
The structure of a machine is very simple, it can be divided into five parts: the body, the rotation, feeding, punching and conveying. These parts cooperate with each other, operate smoothly and steady.
1. The body part is composed of a plate and base. It formed machine frame.
2. Transmission parts: the motor, pulley, gear, transmission shaft and other components. The motor drives the gear shaft to rotate via the belt pulley, and by means of two gear drives the transmission shaft. At the same time, through a pair of bevel gears and a rotating shaft to drive the dial, with the dial turned to drive the four hole disc movement.
3. Feeding part: consisting of a rotating shaft, a hopper, and a stirrer.
Axial turning gears to drives mixer, stir the coal well and into the die cylinder.
4. Punching parts are mainly composed of four sliding rod, a sliding beam, punch, punch, punch, movable platen, movable die bottom and spring.
5. The conveying part is made up of conveying frame, belt pulley, bracket and conveyer belt. The conveying belt is randomly rotated to send the molding coal out of the machine body, and easy adjust the tightness of the conveyor belt by means of the adjustable screw that on the conveying frame.
Raw Material requirement:
- Feeding material size: less than 3mm
- Moisture content: 8-15%
- Binder: we have six different types of binder formula. According to your raw material and final briquettes requirements to add different binders.(liquid and dry powder binder).
- other techniques: The water-proof formula and instant ignite(combustion-supporting)can be provided to our customers for free.
The advantage of Honeycomb briquette machine
- 1. Energy saving, environmental protection, clean and sanitation, no exhaust.
- 2. Flammable, high calorific value.
- 3. Fire flourishing, lasting, and durable; combustion time achieved 80-100 minutes.
- 4. Abundant raw materials and low cost.
- 5: Wide range of applications, environmental equipment
- 6. Easy to adjust the production speed
- 7. No waste and noise, long usage life
- 8. Reliable performance and safe and convenient operation.
Main parameters of mechanical type of Briquette machine
Type | Motor Power(KW) | Capacity(times/min) | Weight(t) | Size of coalball(mm) |
140 | 7.5 | 45 | 1.8 | 140 |
160 | 7.5 | 50 | 2.2 | 160 |
220 | 11 | 26 | 2.5 | 220 |
260 | 11 | 26 | 3.8 | 260 |
In addition, according to different quality of coal and habit, we can provide technical parameters, number of holes, moving blades, briquette, the outer diameter of the power, and special specifications of the mold design to customers. Moreover, based on clients’ requirements, the customized mold can be provided to fulfill the ideal shape, like a rod shape, square shape, round shape, fan shape, flower shape, etc.
Generally, the production line is:
Feeding --> Crushing --> Mixing --> Feeding --> Briquetting.
Our plant has briquette machine series, a series of crusher, also can separately for user planning, design, production, installation of briquette production line and offer the inflammable coal formula and technology.
Packing and shipping
Waterproof packing with the international export standard.
Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box.
Other equipment will be packed in Color-Stripes Plastic Cloth.
In accordance with customer's requirements.
Company profile
Gongyi Lantian Machanical Plant was located in Zhengzhou, Henan province. It has over 20 years history. This company mainly produce all kinds of briquette machines, charcoal equipment, drying equipment and mine equipment, such as ball press machine, coal/charcoal extrude machine, shisha briquette machine, biomass briquette machine, brick briquette machine, pellet machine, honeycomb briquette machine, etc., and all indispensable auxiliary machines.
In 2005, Lantian company has been authorized China Import and export enterprise, ISO international quality certification company, the European Union CE certification enterprises. At present, it has been obtained eight utility model patents, two external appearance patents, and one invention patent. During last 10 years, Lanrtian machinery has been exporting all over the world, such as Malaysia, India, South Africa,Indonesia, Sadi Arabia, Canada, Pakistan, Kuwait, Turkey, Egypt and others.
Service Commitment
Pre-sales service
Providing the project designs and processes flow design.
Draw up the machine equipment purchase plan according to your actual demands.
According to your specific needs to design and manufacture products.
Training technical person for you.
On-sales service
Completing the acceptance of the equipment and assist in the development of construction programs and detailed procedures
After-sales service
Technicians guide the installation of equipment, commissioning and training of operators on the scene.
Tips:
We are Liantian Mechanical Plant with over 30 years experience, and we can provide the whole production line for you.
Our factory was located in Heluo Road, Gongyi City, Henan Province.
The nearest Airport is Xinzheng International Airport, and the airport code is CGO. We can pick you up
Welcome to Gongyi Lantian mechanical plant, we are sincerely looking forward to cooperation with you!
