Lantian Plant Hot Sale Charcoal Rod Maker Charcoal Powder Briquette Machine

Lantian Plant Hot Sale Charcoal Rod Maker Charcoal Powder Briquette Machine photo-1
Lantian Plant Hot Sale Charcoal Rod Maker Charcoal Powder Briquette Machine photo-2
Lantian Plant Hot Sale Charcoal Rod Maker Charcoal Powder Briquette Machine photo-3
Lantian Plant Hot Sale Charcoal Rod Maker Charcoal Powder Briquette Machine photo-4
Lantian Plant Hot Sale Charcoal Rod Maker Charcoal Powder Briquette Machine photo-5
Lantian Plant Hot Sale Charcoal Rod Maker Charcoal Powder Briquette Machine photo-6
US$ 1,800 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Production Capacity:
1-6t/h
Motor Type:
AC Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Tianjin Lianyungang
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Production Capacity 1-6t/h
Motor Type AC Motor
Power(W) 11kw, 18.5kw, 45kw
Place of Origin Henan, China
Brand Name Lantian
Model Number ZBJ-140, ZBJ-180, ZBJ-300
Dimension(L*W*H) According to different type
Certification CE ISO BV
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

  Lantian plant hot sale charcoal rod maker charcoal powder briquette machine



Introduction of charcoal powder briquette machine

Charcoal powder briquette machine, under the action of high pressure, charcoal powder, coal powder, carbon black powder and other powders are extruded into stick shape briquettes, with or without hole in the middle.

The shapes can be finger shape, triangle shape, quadrangle shape, hexagonal, etc. It can be shisha charcoal, silver charcoal and bbq charcoal for different usage. Finished briquettes not only easy to store and transport, but have good performance, miltiple function, also high profit.

Lantian plant hot sale charcoal rod maker charcoal powder briquette machine

 Lantian plant hot sale charcoal rod maker charcoal powder briquette machine



Features of charcoal powder briquette machine



1.Big incoming lathe screw constant and faster material processing rate and energy saving !
2.Rigid connection is used between the shaft block and cylinder. The machine have a stable working performance better than ever.
3.Hydraulic coupler drive is used . So the machine is smooth in operation and have small noise, Also have the function of overload protection.
4.Custom-made services are provided.

Lantian plant hot sale charcoal rod maker charcoal powder briquette machine



Application of charcoal powder briquette machine



Carbon black,charcoal,coal,coke,iron powder,mill scale,burnt lime,aluminum dross,iron ore fines,sodium carbonate,flue dust,manganese ore fines.

Lantian plant hot sale charcoal rod maker charcoal powder briquette machine





Working principle of charcoal powder briquette machine



Our charcoal powder briquette machine feed the ratio and retting coal powder mixture into a nitrogentreated barrel by the extrusion of principle , which will compress into section for round, hexagon form or other shape.The final coal/charcoal rods have a certain mechanical strength by formed in this equipments.

Lantian plant hot sale charcoal rod maker charcoal powder briquette machineLantian plant hot sale charcoal rod maker charcoal powder briquette machine





Technical parameter of charcoal powder briquette machine

Model

MB140

MB180

MB300

Capacity ---Charcoal

400-600kg/h

600-800kg/h

2000-3500kg/h

Capacity ---Coal

1-2t/h

2-3t/h

4-6t/h

Diameter (mm)

20-40

20-60

20-80

Motor power

11 kw

18.5kw

45kw

Weight

0.6 t

0.8 t

1.2 t

Dimension

1.87*0.9*1.15 m

2.35*0.9*1.37 m

 2.7*1.25*2 m







Production line of charcoal powder briquette machine

(1).Binder mixer: It is using for dissolving and thicking binder.

(2).Crusher and mixer: It is a machine with the function of crushing and mixing together, crushing the raw material below 5mm, and mixing them uniformly. The moisture need controlled between 25%-30%.

(3).Coal briquette machine: It presses coal powder, charcoal powder, or other powders into different shapes and size.

(4).Dryer. We have vertical dryer, box dryer and mesh belt dryer. I will suggest suitable dryer according to your raw machine, shape and size.

Lantian plant hot sale charcoal rod maker charcoal powder briquette machine





Shipping of charcoal powder briquette machine

(1)Wrapped with plastic,then in free fumigation wooden case with steel frame.
(2)Wrapped with plastic,loaded in standard container 20GP,40GP,40HP
(3)Nude packing, then in standard containder.

Lantian plant hot sale charcoal rod maker charcoal powder briquette machine





Our service



(1)Pre-sales service

a. Sales team will suggest suitable project.

b. Technical team analyse and design special molds for you.

c. Pick you up at airport, arrange hotel-booking.

d. Other travel arrangements.



(2)After-sales service

a. Assist you build up factory and production line.

b. Install and maintain machines.

c. Training your workers to achieve skillful operation.

d. Offer technical support through telephone or online videos at any time.

Lantian plant hot sale charcoal rod maker charcoal powder briquette machineLantian plant hot sale charcoal rod maker charcoal powder briquette machine





Company introduction



We are a 30 years factory located in "mechanical city" Gongyi city, Henan province, China. 30 dedicated development, we have become to a factory including design, manufacture, sale and after-sales service. Good product quality and finest after-sales service are our intention and goal.

Our main products are different kinds briquette machines, coal briquette machine, charcoal briquette machine, shisha charcoal briquette machine, biomass briquette machine, and other auxiliary machine crusher, dryer, feeder, conveyor machine, mixer, etc.

Lantian plant hot sale charcoal rod maker charcoal powder briquette machineLantian plant hot sale charcoal rod maker charcoal powder briquette machine
