High Capacity Good Quality Wood Carbonizing Furnace Charcoal Kiln Wood Furnace

High capacity good quality wood carbonizing furnace charcoal kiln wood furnace

Round shape

Square shape

Wood carbonizing furnace description

This one set carbonization furnace including one main furnace,3 inner baskets and hoisting tools.

When the buyer download the raw material into the inner basket,they could use cages for loading.

After the carbonizing time for one inner basket is around 8-10 hours,we could take the inner basket out and let it cool,then put another inner basket inside.

After the temperature get around 300-330℃,we could stop heating and it will produce gas,the gas will return main furnace by pipes,it will self-heating.

Structures of wood carbonizing furnace

Our machine is mainly consist of furnace body, furnace lids, heating chamber, exhaust pipes and inner furnaces. Our inner furnaces don't connect with the machine body, after carbonization, they can be hoisted away from the machine body, thus one machine can be matched with extra sets of inner furnaces, which greatly increases the working efficiency!

Features of wood carbonizing furnace

1.This machine is used to carbonized the half-product into finished product.

2.It is equip-ed with hyperploid high temperature steam cooling system, and the process of cooling can be accelerated to speed up the period of the production.

3.Carbonization furnace is a stove used to change biomass briquette into charcoal briquette.

4.The quality and efficiency of kiln affect final forming of charcoal briquette greatly.

5.This furnace is ideal equipment for wood briquettes to have anoxic distillation carbonization. Due to its rational structure.

6.the furnace only needs small quality of heat consumption.

Application of wood carbonizing furnace

All kinds of biomass material: Friut Husk,Wood Scraps and Crop Stalks,

Friut Husk---Rice husk, Coconut shell, Peanut shell/ Groundnut shell, Sunflower seed husk/shell, Palm kernel shell, Walnut shell, Almond shell, Pistachio shell etc..

Wood Scraps---Wood sawdust,Forest farm & furniture factory scraps, Wood shavings, Wood chips, Tree branch, Bamboo scraps, Sugarcane bagasse, Distillers grains, Coffee grounds, coco husk chips, Waste from beer breweries, Empty Fruit Bunch etc.

Crop Stalks---Plants straw, Crop residues, Soybean straw, Wheat straw, Cotton straw, Corn stalks, Sorghum stalk, Maize Cob/ Corncob, Sorghum husk/ shell/hull, Potato grass, Dead leaves etc.

Materials requirements

Particle size is less than 50 mm, water content <25% of biomass particles can feeding into the type A carbonizing directly, such as: sawdust, rice husk, shell, palm shell, peanut shell, bamboo shavings, shavings etc.;

When you carbonize larger raw materials (Particle size more than 50 mm), such as branches, bark, coconut shell, such as straw, hemp pole, peduncle, need to crush it into less than 50mm pieces firstly; If water content is more than 30%, you can choose type B machine for production.

Working principle of wood carbonizing furnace

1.Heating process: After putting the inner baskets into the furnace, we need to heat the furnace up to 80-120mins, the temperature get around 300-330 ℃,it will produce the gas(CH4,C2H4) or biomass waste as fuel,at this time,we stop heating.
2.Carbonizing process: After doing the sealing work, the materials inside begin to pyrolysis, it will produce gas at this period, so we need heating in this process, the carbonization time is often around 8-12hours.
3. Cooling process: After carbonizing, we need to take the inner basket out , let it cool by natural way, cooling time is often around 8-10 hours. Cooling time is longer, it is better for stove quality
4. After taking the inner basket out, we need to put another basket inside, this is the cycling process.

Technical parameter of wood carbonizing furnace

Wood carbonizing furnace shipping

Usually, due to large volume, the carbonization furnace is loaded in 20GP standard container.

FAQ

(1)What is your business model? Trading company or factory?

We are a 30 years factory, all our machines are manufactured by ourselves, factory direct sales, product quality and after-sales service can be guarantee.

(2)What is the carbonization rate?

This carbonization rate can reach 99%.

(3)Could you offer complete briquette machine production line?

Yes, we will allocate suitable production line, according to your special requirement, such as crusher, conveyor, dryer, briquette machine, etc.

(4)Where is your factory located? How I get to?

We are located in Gongyi city, Henan province, China, you can come here by air or train.

The nearest airport is Zhengzhou Xinzheng International Airport, and the Airport Code is CGO

We will pick you up at airport. Welcome to visit our factory.

Our service

Pre-sale:

1. Suggest to client suitable raw material, final product capacity.

2. Introduce machine's structure and features in detail, explain the price component;

3. answer client concerned questions.

After-sale:

1. Start production as soon as receiving down payment.

2. Send photos of machine in manufacturing and finished photos to client, for your better learn about the machine's condition.

3. Delivery machine in time, taking photos during loading, so you can "remote monitoring" your goods.

4. Documents and certificate available in time.

5. Manual documents available. Engineer can be sent to client site for installation instruction.

Our company

We are a 30 years factory, has 30 years manufacturing experience and 6 years exporting experience. Our factory are specialized in charcoal machinery, briquette machinery and mining equipment.

 Until now we have many customers come from different countries:

Asia countries:  Philippines, Vietnam,Thailand, Malaysia, Singapore, Indonesia,  Bangladesh, India, Pakistan, Sri Lanka, Kazakhstan, Uzbekistan, etc.

Afghanistan, Iran, Iraq, Jordan, Lebanon, Saudi arabia, Turkey, etc.

Euopean countries: Russia, Spain, Romania, Bulgaria, greece, etc.

African countries: Egypt, Libya, Sultan, Tunisia, Algeria, Kenya, Tanzania, South Africa,etc.

Oceania countries:  Australia, New Zealand, etc.

America countries: Mexico, Venezuela, Chile, Brazil, Argentina, etc.

If you have any other questions about the machine, please send the inquiry. Contact with me at any time!
