Home > Products > Gypsum Powder Production Line > gypsum powder production line/ machinery
gypsum powder production line/ machinery
- 20 Set / Sets per Month
- Tianjin
- T/T Credit Card
Product Details
Condition: | New | Automatic Grade: | Automatic | Place of Origin: | Hebei, China |
Brand Name: | Fuchen | Model Number: | FC | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1. gypsgood service2. low cost and consumption
3. different production capacity
4. CE certificate
5. simple operation
high efficiency Gypsum powder production line
usage
This machine is mainly applied in metallurgy, building materials, chemicals, grind of mine materials, etc. It
can grind quartz, feldspar, calcite, talcum, barite, fluorite and heat preserve, etc. Manufacture non-flammable
and explosive mine materials, whose hardness should below 9.3, and the humidity at 6%.
Six features
1.. Compared with other grind, the output of this machine increase of 20-30% under the same power
conditions. Under high pressure of magnetic, which obtain from spring, the magnetic pressure from grind
roller to materials increase 800-1200 kg.
2. The mine materials, whose hardness below 9.3 can be break.
3. Finished products cover a wide range of size, diameter of rough particle up to 0.613 mm (30 mesh), diameter of generally particle up to 0.033 mm (425 mesh), a small number of the materials can be as small as 0.013mm (1000mesh).
4. Dust remover effect up to National dust emission standard.
5. Facilitate machine adjust conveniently.
6. Grinding device adopt multi-seal, so it can seal well.
Main structure and principle
The machine mainly makeup by mainframe, the fineness machine, blowers, finished product Tornado Mill,
bag filter and the bond wind tube, according to needs of user, it can be equipped with broken machines, lifter,
storage hopper, and electromagnetic vibration feeder machine, Electrical control cabinet, and other peripheral.
In the mainframe , grind roller hanging on shelf of grind roller via cross axis. Grind roller shelf have fixed link
with main axis and shovel knife shelf. The pressure spring pressure in the arm surface of grind axis room. The
grind take cross axis as the fulcrum and force grind roller pressure on the inner surface of grinding ring. When
the motor driven the main axis through the transmission device, knife installed on the shelf will rotate with the
grind roller. Grind roller will autobiography when grind roller is rolling at inner circle. Motor driven analysis
wheel to transmission via convey device, the higher the convey speed, the smaller the block is.
Work process of grind machine: Bulk materials are broken up, then be sent to the storage hopper by the hoist,
and then evenly into the mainframe grinding room from vibration feeder machine, the materials in grinding
room take by shovel knife then go to the central of grind roller and grind circle to break, the air blower blow
the air to grind room from the frame around, take the materials into the analysis machine, the big blocks back
to re-grinding, qualified powder into cyclone powder collection hopper, small powder separate from air
and discharge from the mouth of material off-load. The air will go to wind machine from onside, repeat
this process.The grinded materials contain a certain moisture when it is in the grind room. Heat was produced when
grinding. It leads to evaporation of water, outside gas was inbreathed because the tube connection is not rigor, the air
circulation increased. To ensure negative work of grind under pressure, the increased gas flow into the bag filter through the
remainder gas tube between wind machine and mainframe, set out to the air after being purify.
