Landing Gear Mobile Dock Ramp

Landing Gear Mobile Dock Ramp photo-1
US$ 3,300 - 3,300 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
no
Model Number:
no
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shandong, China
Brand Name no
Model Number no
Lift Mechanism Articulated Lift
Lift Drive / Actuation Hand
Power 2.2kw
Rated Loading Capacity 10000kg
Min. Lifting Height 0.9m
Max. Lifting Height 2m
Table Size 10500*2000mm
Overall Dimensions 11*2.08*1.3m
Weight 1500kg
Certification CE ISO
Warranty 1 year
After-sales Service Provided No overseas service provided

Landing Gear Mobile Dock Ramp

Landing Gear Mobile Dock Ramp

Mobile Dock Ramp Manufacturer Information

1> The regular mobile of this ramp is : width -2m length -11.2m,

2> Adjusting height range -0.8m-1.85m,

3> And it aslo can be designed and produced accordign to customers requirements .

4> This machine is suit for :often materail handling ,warehouse .wharf ,logistics center working place



Mobile Dock Ramp Manufacturer (with landing gear) Dimension

1

Model Number:

WDMYR-10

2

Rated Loading Capacity:

10 Ton

3

Working form:

With landing gear (manual one)

4

Max adjustable height:

1800mm

5

Overall length* Overall width:

11200*2100mm

Platform Size:

2400*2100mm

Slope Size:

7500*2100mm

6

Table Material:

Gear steel grating   (Function:anti-skidding, avoid ponding)

7

Lifting plate:

Size:1000mm        Plate Lip: 300*20mm

8

Landing gear

Quantity: 1 Pair      Static Load: 40 TON

9

Solid tire

Size: 500-8B          Diameter:450MM

10

Safety locking

Quantity: 2 pcs

Function: lock the container when loading and unloading






Mobile Hydraulic Yard Ramp

Model

Lifting height

(m)

Lifting weight

(kg)

Platform size

(mm)

Overall dimension

(mm)

Power supply

(kw)

Total weight

(kg)

WLD-4

0.9-1.7

4000

10500*1900

10500*2000

Manual operation

2200

WLD-6

6000

2300

WLD-8

8000

2500

WLD-10

10000

2800

WLD-12

0.9-1.6

12000

3400


Certifications

at moment, we have the certificate of the CE and the ISO,also we have our own provment for the products.these could show our products a high quality to you.
