solar water heater
Specifications: |
1) Highly efficient heat pipe technology :Heat Pipe Plus Vacuum Tube structure, no any water in tube, if tube broken, the water not lose.
2) High pressure storage tank (Testing pressure = 12 bar),
3) inner tank material :: enamel tank,2.0mm or stainless steel 1.2mm
4) No sealing rubber is needed and hence no leaking problem
5) Easy plug-in installation, Anti-freeze
1.Inner Tank: Stainless steel ,1.2mm
2.Outer tank: colourful steel(galvanized steel) or stainless steel 3042B(BA),outer diameter:470mm
3.Vacuum tube: High-efficient vacuum tube (58mm 1800mm) Hail resistance: 25mm
4.Supporting Frame: Galvanized steel Sheet or Stainless steel sheet,Angle:20-80 degree.
5.Insulating Layer: Foaming polyurethane, Thickness 55mm
6.Working Pressure : 6-8bar
Technical Info: |
Inner Tank | 304/316L Stainless steel or Porcelain enamel |
Outer Shell of Tank | Galvanized steel Sheet or Stainless steel sheet |
Supporting Frame | Galvanized steel Sheet or Stainless steel sheet |
Insulating Layer | Foaming polyurethane, Thickness:55mm |
Working Pressure | Normal working pressure: 7bar Test pressure: 11bar |
Electric Booster | 1500W |
| Model | Light Area(m2) | Vacuum Tube | Tank Net Capacity (Liters) | ||
| Ø(mm) | L(mm) | NO . | |||
| SGCB47581810-GS | 1.4 | 58 | 1800 | 10 | 85 |
| SGCB47581812-GS | 1.68 | 58 | 1800 | 12 | 100 |
| SGCB47581815-GS | 2.1 | 58 | 1800 | 15 | 125 |
| SGCB47581816-GS | 2.24 | 58 | 1800 | 16 | 135 |
| SGCB47581818-GS | 2.52 | 58 | 1800 | 18 | 150 |
| SGCB47581820-GS | 2.8 | 58 | 1800 | 20 | 165 |
| SGCB47581824-GS | 3.36 | 58 | 1800 | 24 | 210 |
| SGCB47581830-GS | 4.2 | 58 | 1800 | 30 | 260 |
| SGCB47581810-SS | 1.4 | 58 | 1800 | 10 | 85 |
| SGCB47581812-SS | 1.68 | 58 | 1800 | 12 | 100 |
| SGCB47581815-SS | 2.1 | 58 | 1800 | 15 | 125 |
| SGCB47581816-SS | 2.24 | 58 | 1800 | 16 | 135 |
| SGCB47581818-SS | 2.52 | 58 | 1800 | 18 | 150 |
| SGCB47581820-SS | 2.8 | 58 | 1800 | 20 | 165 |
| SGCB47581824-SS | 3.36 | 58 | 1800 | 24 | 210 |
| SGCB47581830-SS | 4.2 | 58 | 1800 | 30 | 260 |
Certificate: Solar Keymark, SRCC, ISO9001, CE
