solar thermal water heater
Pressurized solar water heater(thermosiphon) provide energy and get hot water by a efficient coppper coil fixed in water tank. Different from other common solar water heaters, this type could be used pressurized. As water in tank can store energy, when cold water goes through copper coil, it could absorb heat from water in tank. The copper coil is20-60 m long.
Tank installation should be according to local condition. Thermosiphon solar water heater system is suitable for family, swimming pool ,solar water furnace system and floor heating. It is suitable in areas with cold weather and bad-quality water.it could be used as pressurized system , with much lower price than solar water heater with pressurized water tank.
1. Use in any time: it adopts advanced design idea and integrates with high efficiency preheated patent technique, so it can warm the cold water rapidly when it flows through special pipe. It can overcome the short of traditional SWH, such as sloe heating, long waiting time.
2. More capacity: we adopt special exchanging heat mode, it avoids mixed effect, so cold water can be heated at any moment.
3. Strong hydraulic pressure: the hydraulic pressure is same as tap water, it is very suitable for tired person.
4. Economical and Environment protecting: there is no pollution when it is working since it depends on sunshine. Green and economical.
5. Easy operation: it can supply water automatically, you can take it easy and enjoy good time.
6. Fashionable: the appearance is fashionable and it can great integrate with you fitment.
7. No corrosion or scaling:as almost no wateris introduced into the tank (apart from occasional topping up), so corrosionscale buildup is almost totally eliminated.
Copper Coil Heat Exchanger Specifications | |
HE Material |
Diameter:12mm,14mm,16mm; thickness :1.0mm copper pipe |
HE Surface Area |
1.5m² for 30 tube water heater |
HE Testing Pressure |
9 bar |
| Model | Light Area(m2) | Vacuum Tube | Tank Net Capacity (Liters) |
Overall Capacity (Liters) | ||
| Ø(mm) | L(mm) | NO. | ||||
| SGZZ 47581816-GS | 2.24 | 58 | 1800 | 16 | 133 | 183 |
| SGZZ 47581818-GS | 2.52 | 58 | 1800 | 18 | 150 | 206 |
| SGZZ 47581820-GS | 2.8 | 58 | 1800 | 20 | 165 | 227 |
| SGZZ 47581824-GS | 3.36 | 58 | 1800 | 24 | 200 | 274 |
| SGZZ 47581830-GS | 4.2 | 58 | 1800 | 30 | 250 | 343 |
| SGZZ 47581836-GS | 5.04 | 58 | 1800 | 36 | 300 | 412 |
| SGZZ 47581816-SS | 2.24 | 58 | 1800 | 16 | 133 | 183 |
| SGZZ 47581818-SS | 2.52 | 58 | 1800 | 18 | 150 | 206 |
| SGZZ 47581820-SS | 2.8 | 58 | 1800 | 20 | 165 | 227 |
| SGZZ 47581824-SS | 3.36 | 58 | 1800 | 24 | 200 | 274 |
| SGZZ 47581830-SS | 4.2 | 58 | 1800 | 30 | 250 | 343 |
| SGZZ 47581836-SS | 5.04 | 58 | 1800 | 36 | 300 | 412 |
| SGZZ 47471518-GS | 1.62 | 47 | 1500 | 18 | 135 | 164 |
| SGZZ 47471520-GS | 1.8 | 47 | 1500 | 20 | 150 | 182 |
| SGZZ 47471524-GS | 2.16 | 47 | 1500 | 24 | 175 | 213 |
| SGZZ 47471530-GS | 2.7 | 47 | 1500 | 30 | 220 | 268 |
| SGZZ 47471536-GS | 3.24 | 47 | 1500 | 36 | 260 | 318 |
| SGZZ 47471518-SS | 1.62 | 47 | 1500 | 18 | 135 | 164 |
| SGZZ 47471520-SS | 1.8 | 47 | 1500 | 20 | 150 | 182 |
| SGZZ 47471524-SS | 2.16 | 47 | 1500 | 24 | 175 | 213 |
| SGZZ 47471530-SS | 2.7 | 47 | 1500 | 30 | 220 | 268 |
| SGZZ 47471536-SS | 3.24 | 47 | 1500 | 36 | 260 | 318 |
Certificate: Solar Keymark, SRCC, ISO9001, CE
