corn hammer mill for sale, feed hammer mill price
♣ Description for corn hammer mill for sale, feed hammer mill price
Hammer mills are mostly impact grinders with swinging or stationary steel bars forcing ingredients against a circular screen.Material is held in the grinding chamber until it is reduced to the size of the openings in the screen. The number of hammers on a rotating shaft, their size, arrangement, sharpness, the speed of rotation, wear patterns, and clearance at the tip relative to the screen are important variables in grinding capacity and the appearance of the product. Heat imparted to the material, due to the work of grinding, is related to the time it is held within the chamber and the air flow characteristics. Impact grinding is most efficient with dry, low-fat ingredients, although many other materials may be reduced in size by proper screen selection and regulated intakeThis hammer mill is widely applied in grinding various grains such as corn, broomcorn, wheat, barley, bean and ground cakes and etc.. double crane brand waterdrop feed hammer mill is favored by large and medium sized feed plant, food processing enterpriseand so on.
♣ Features for corn hammer mill for sale, feed hammer mill price
1.It is a universal type product a mostly used for micro crushing with stable performance, It is widely used in small and medium and food processing industries for raw material grinding.
2.The overall base design make it have higher structural strength and beautiful in appearance.
3.Direct transmission and advanced serpentine spring coupling are used, the reasonable arrangement of hammers and clearance between hammers and screens make sure the final product s are in uniform fineness.
4.Secondary grinding technology is used in this hammer mill. The iron casting secondary grinding chamber has high level of abrasive resistance.
5.Imported high quality bearing is used to make sure the hammer mill have lower operation temperature . The imported SKF bearing housing is equipped with bearing temperature indicator.
6.Many kind of mesh specification can be chosen. Quick starting type door opening machinery and frame type screen pressing mechanism are used,which can make the screen fixed solidly and fast to change the new screen.It is easy to operate and convenient to maintain. 7.The hammer is sprayed and welded with carbon tungsten alloy can ensure long life service.
♣Technical Data for corn hammer mill for sale,feed hammer mill price
| Item Name | SFSP56*32 | SFSP56*40 | SFSP60*60 | SFSP66*80 |
| Motor Power(KW) | 22/30 | 30/37 | 55/75 | 90/110 |
| Production Capacity | 1-2t/h | 3-5t/h | 4-12t/h | 5-15t/h |
| Hammer Quantity | 30pcs | 48pcs | 70pcs | 90pcs |
| Screen Quantity Screen | 2pcs,high output,good crush effect | |||
| Screen Hole Diameter | 1.5,2,4,6,8,10,12mm | |||
| Main shaft Speed ( rpm ) | 2970 | |||
| Bearing Number | 2312 | 2314 | 2214 | 2218 |
| Screen Size(mm) | 840*270*2 | 712*395*2 | 850*618*2 | 850*795*2 |
| Anti-vibration Pad | 4 | 4 | 4 | 6 |
| Dimension(mm) | 1450*850*950 | 1530*860*1130 | 1950*950*1150 | 2550*1150*1350 |
| Weight | 800kg | 1000kg | 1500kg | 2500kg |
♣ Working Principle for corn hammer mill for sale,feed hammer mill price
The major working part of hammer mill is rotor with hammer. The motor will generate rotor to complete
the high-speed rotation within the wide crushing chamber. Materials are coming into hammer mill through
the upper inlet, then they are striked and impacted by high-speed rotating hammer and gradually become
small size particles. The smaller sized particles is discharged through the screen in feed grinding machine
by centrifugal force and air flowing, as the bigger particles can be still left within the sieve, and they are
still be blown and crushed by hammer. Eventually, they may be discharged by way of sieve from pellet
machine.
♣ Appication for corn hammer mill for sale,feed hammer mill price
It is used in large /middle/small feed mill or private farm as a crushing section to crush maize,soybean,wheat,rce husk and the like into powder or particles .
♣ Certificate for corn hammer mill for sale,feed hammer mill price
Shandong Double Crane Machinery Manufacture Co.,Ltd. is located in economical and technological
development zone, Leling city,Shandong province,very close to the expressway from Beijing to Shanghai.
Our company is the high and new technological enterprise dedicated to manufacture feed pellet machines and biomass pellet machines to worldwide users.
Sticking to the product developing ideas of simplicity,perfection,quality and innovation,we have been always focused on designing and manufacturing feed pellet machines and biomass pellet machines since the foundation in 2005.
We had cooperated with domestic famous universities like Shandong University,Jinan University and Shandong Agricultural University in feed pellet production line and biomass pellet production line research and development.
since 2008.We had obtained more than 30 patents and successfully developed 8 series of products,including 60 different kinds of machines.In the feed pellet industry ,we had achieved advanced level in man-machine design,functional design,automatic control and user experience and became the professional pellet mill manufacturer in China.We have strong competitive advantages in feed production line with the capacity of 1-30 tph and biomass pellet complete line with capacity of 1-50tph.Until now,we had installed more than 1200 sets of machines worldwide.
In recent years,our company continuously increase investment.We had invested up to 60 million Yuan to build19,200 square meters manufacturing base and 10 million Yuan for technological innovation,in-depth automatic and integrative technology development.These investments have greatly promoted the upgrading of the machines,offering best quality solutions for feed industry and biomass pellet industry.Double Crane Machinery is willing to become your partner with our high price-performance products,excellent quality and perfect after-sales service.
Promise provide customer Best Quality! Best Price! Best Service!
Packed into wood case loaded into container
2.Our professional service include:free training,guidance,onsite installation,and debugging.
3.After selling, we provide the warranty of one year and free technical guidance and spares parts supply.
4.If your equipments have any problems, we will help you to solve online or onsite in time.
5.Welcome oversea agents to join us expand internation market.
1.Are you manufacturer or trading company?
R:Our company is manufacturer and public company,we have been specialized in this field more than ten years.our company's factory covers an area of 67000 square meters,registered capital 60 Million RMB.Located in Dezhou city,Shandong Province.
2.How can we promise the equipment quality?
R:Our company pass European Union GS Safety Certification,ISO9001 Quality Management System
Certification, Chinese Credit Enterprise Association, AAA Quality Credit Enterprise Member,
Well-known Trademarks In China.We have professional R&D and production team can promise all equipment is qualifyed befor deliver to customer.
3.If we want to establish a feed production line,can you help us?
R:Yes,our company can provide service of free design,training,guidance,onsite installation,and debugging.
Only need customer tell us which type animal feed do you want to produce,production capacity demand,
we will recommend you the best design and offer.
Welcome your inquiry and we will reply you within 12 hours !
