Large Scale Animal Feed Pellet Plant, Poultry Chicken Feed Pellet Mill Manufacturer

1. SZLH-350 Animal Feed Pellet Production Line Plants Introduction:

1.1 The product capacity SH350 production line is 5-6t/h,

1.2 SH-350 12 silo automatic batching feed pellet production line is a large feed pellet plant,through computer control automatic batching system,it easy to adjust feed formulation and feed material mix proportion.it have 12 batching silo can matching 12 kinds of feed material,thus can meet customer different animal feed production demand.it not only can produce feed pellet for poultry feed (chicken feed, duck feed, etc), but also can produce livestock feed (cattle feed, sheep feed, rabbit feed, etc).

1.3 This type feed pellet production line can process all kinds of animal feed material,such as corn,soybean,

wheat bran, sorghum, bone, fish, straw power, crushed grass, etc. it is very suitable to produce pellet feed and premix/ powder/ mash feed for chicken,duck,rabbit,pig,fish, shrimp,cattle,cow,sheep feed,etc.

2. Flow Chart for SZLH350 Poultry Feed Product Line

3. SZLH-350 Poultry And Livestock Feed Pellet Plants Product Process

3.1. Feed materials receiving and cleaning system:

Before going into the main equipments,feed raw materials should be cleaned to remove impurities and iron parts in order to ensure the product quality and normal working of the main equipments.

3.2. Feed crushing system:

All big size feed raw materials should be grinded to small pieces or powder feed by hammer mill,hammer mill sieve can be 2,4,6,8,10mm..

3.3. Feed automatic batching and mixing system:

Bucket elevator transport each crushed feed into 12 pcs of batching silo,by computer accoriding to feed formulation to match different feed into paddle mixer,mixer blend feed evenly.

3.4. Feed pelletizing system (Including steam conditioning system):

Adopt ring die feed pellet mill produce feed pellet with high production capacity and high grade pellet feed production effect. Ring die feed pellet mill can produce feed pellet,diameter 2-8mm,according to customer demand.

Steam boiler system supply steam to conditioner device,it can cooking and modulating feed improve feed moisture and temperature, steam conditioning equipment can improve the material granulating, increase production capacity, save the energy consumption of the granulating, improve the use life time of pelletizer ring die and roller.

3.5. Feed pellet cooling system:

Produced feed pellet temperature vey high,it can't suitable to pack directly,so need pellet cooler machine cool down pellet feed temperature,by cooler machine can make pellet temperature room temperature+3 degree.

3.6. Feed pellet crumbling system:

Feed pellet crumbler is optional. can use crumbler to broke feed pellet for small chick feed.

3.7. Feed pellet sieving system:

We use rotary screener to sieve the feed pellet. Sieve the qualified pellet feed to sale.

3.8. Automatic packing system:

Independent packaging system, high precision and package speed,save labor.

4. Main Machine in SZLH350 Poultry Feed Production Line

 The machine For SH250 Product line with plastic film will packing into one 40' container as below photos, If you have any special request. We will packing as your request.

 Shandong Double Crane Machinery Manufacturer Co., Ltd was found in 2005. It located in Leling town, Dezhou city, Shandong province. Our company is specialized in feed machine, grass machine, chemical machine and organic fertilizer production machine for more than 10 years. and independent innovation and first develop biomass briquetting complete set in China. The main raw material is sawdust, straw, Grain, fiber. etc., In order to ensure the high quality product and make it meet different client requirement, Our company retain well known agricultural experts and skilled engineer to make more new designs and improve the product process.

Our main product contain hammer mill, double shaft/single shaft mixer, plat die/ring die pellet mill,counter flow cooler, different type screener, wood chipper, chaff cutter, airflow drier, and transfer equipment,such as bucket elevator, screw conveyor.Our product is honored with the authoritative certifications, such as SE,GS Safety Certification,ISO9001 Quality Management System Certification,
Our products enjoy extremely high reputation both at domestic market and abroad, such as in South Korea, Vietnam, Philippine,Thailand, Malaysia, Australia, Russia,America, Finland, Spain, Bulgaria,Africa and other countries and regions.

 1. Q: Are you a trading company or a manufacturer?

A: We are top manufacturer which specialized in this feed machine field for more than 10 years and also high reputation in China.Our factory cover 67000m2 and annual sale is 60 million.
2. Q: The MOQ for your product.
A:The MOQ for our product is 1 set.
3. Q: Do you provide the after-sale service?
A: Yes. The warranty period of our machines is one year, (Calculated from the equipment arrives the customer’s side). and we have a professional after-sale service team to promptly and thoroughly solve your problems.
4. Q: Will you dispatch engineers to guide installation the plant?
A: yes, but at an extra cost payable by the customer. Or you can get local contractors to do the commissioning and we send one supervising engineer.
5.Q: Do you provide product flow chart?
A:Yes. Our experienced engineers are specialized in designing process flow for various project.
6. Q: Have you sold your products to Europe?
A: Yes, We have designed and installed more than 1000 turnkey pellet lines. Many of our customers are from Europe, including Latvia, France, Grezece, Romania, Lithuania, etc.
7. Q: How can I get to your company?
A: You can get a flight to Jinan Airport and We are just about 1hours away from Jinan Airport. Or you can flight to Beijing or Shanghai and then take the high-speed train (G-train). The nearest railway station is Dezhou East station.
