ISO Standard Ring Die Wood Pellet Machine for Biomass Burner

ISO Standard Ring Die Wood Pellet Machine for Biomass Burner photo-1
US$ 28,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
ROTEX MASTER
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name ROTEX MASTER
Model Number YGKJ560
Voltage 380V 50Hz 3Phase
Power(W) 90KW
Dimension(L*W*H) 2600x1300x2300mm
Weight 5.5T
Certification CE ISO SGS
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Ring die wood pellet mill
1.output:1-1.5t/h
2.pellet diameter:4-12mm
3.wood pellet machine
4.CE ISO



  ISO standard ring die wood pellet machine for biomass burner



YGKJ series wood pellet mill







Product Description

Brief introduction of YGKJ series wood pellet mill

Vertical and double layer dies. both of the dies and compression rollers are adopt high alloy wear-resistant

materials, with rational design, unique structure, stably and efficiently characteristics of a long life.



Raw material application

The pellet mill is suitable to make no oily and which are dried by driers, such as rice husk, sawdust,

cotton stalks, cottonseed skins, rank grass, and other crops straw and plant waste.

The equipment is also widely used in power plant, wood processing plant and biomass fuels plant.



Technical parameter of the YGKJ series wood pellet mill







Model

Power

(Kw)

Pellet Diameter

(mm)

Die Diameter

(mm)

Output Capacity

(t/h)

Dimension

(mm)

Weight

(t)

YGKJ550

75

4-12

550

0.7-1

2300x1000x1780

4.8

YGKJ560

90

4-12

560

1-1.5

2600x1300x2300

5.8

YGKJ580

160

4-12

580

1.5-2

2900x1300x2400

6.5

YGKJ850

220

4-12

850

2-3

3750x1650x3250

12.6









Pictures of YGKJ series wood pellet mill



ISO standard ring die wood pellet machine for biomass burner

 ISO standard ring die wood pellet machine for biomass burnerISO standard ring die wood pellet machine for biomass burner



Main parts of wood pellet machine



ISO standard ring die wood pellet machine for biomass burner

ISO standard ring die wood pellet machine for biomass burner







Sample made by the YGKJ series wood pellet mill



ISO standard ring die wood pellet machine for biomass burner

ISO standard ring die wood pellet machine for biomass burner



Company Information



Shandong Rotex Machinery Co.,Ltd is an enterprise of research and development, manufacturing, international trade as a whole, registered capacity is 10 million Yuan, more than 150 staff. Strong technical force, advanced production technology, perfect after-sales service.

Mainly produce: biomass fuel pellet production line, feed pellet production line, organic fertilizer and Municipal Solid Waste processing equipment, agricultural equipment, forestry equipment, etc.

ISO standard ring die wood pellet machine for biomass burner

Certificate For the YGKJ series wood pellet mill

ISO standard ring die wood pellet machine for biomass burner
