Floating Fish Food Extruder

Floating Fish Food Extruder photo-1
US$ 5,540 - 856,280 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
JC
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao china
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name JC
Model Number JCYG60
Type Feed Pellet Machine
Voltage 380V
Power(W) 45
Dimension(L*W*H) 14.5*3.2*7.5
Weight 5600 kg
Certification CE
Warranty 2 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Floating Fish Food Extruder
1.For fish, dog, poultry
2.Pellet size 1.2~16mm
3.Floating

Floating Fish Food Extruder



Floating fish feed machine is widely used for producing grains into high-grade aquatic feed pellets for fish, catfish, shrimps, crab etc.
The puffing fish feed pellets can float on the water surface without dissolution for over 12 hours. According to your requirements and production scale, floating fish feed machine can be classified into dry type machine and wet type machine.



Floating Fish Food Extruder--Application and features:

1.According to different requirements, variety shapes of high-grade feed pellets for fish, shrimps .etc can be produced.

2.The finished pellets can keep floating for 3-15 hours without pollution to water.

3.The floating time can be controlled by the puffing degree adjustment.

4.Floating fish feed machine can make pellet from dia.1.0mm-20mm just by changing the mold.

5.Electric heating device is adopted which can improve the feed expansion rate and pellets floating time.

6.High temperature and high pressure cooking process can kill the salmonellosis and bacterial infections and also makes the pellets easily to digest.

7.The cutting device can be adjusted to make pellets of different length.

8.The wet type machine needs a boiler to make steam which can conduct steam to the conditioner and ripen the raw material in advance.




Floating Fish Food Extruder-- Dry type:

Model

Capacity

 t/h

Main power

 kw

Feeding Power

kw

Screw diameter

mm

Cutting Power

kw

JCYG50S

0.06-0.08

0.4

0.4

Φ50

0.4

JCYG60S

0.12-0.15

15

0.4

φ60

0.4

JCYG70S

0.18-0.2

18.5

0.4

φ70

0.4

JCYG80S

0.2-0.25

22

0.4

φ80

1.1

JCYG90S

0.32-0.35

37

1.1

φ90

1.5

JCYG120S

0.5-0.6

55

1.1

φ120

2.2

JCYG135S

0.7-0.8

75

1.1

φ133

2.2

JCYG160S

1-1.2

90

1.5

φ155

2.2

JCYG200S

1.8-2.0

132

1.5

φ195

3.0

Floating Fish Food ExtruderFloating Fish Food Extruder



Floating Fish Food Extruder--Wet Type:

Model

Capacity

t/h

Main power

kw

Feeding Power

kw

Screw diameter

mm

Cutting Power

 kw

Conditioner Power

 kw

JCYS60S

0.18-0.2

15

0.75

60

0.75

0.37

JCYS70S

0.25-0.30

18.5

0.75

70

0.75

1.5

JCYS80S

0.35-0.40

22

1.1

80

0.75

1.5

JCYS90S

0.50-0.60

37

1.1

90

1.1

2.2

JCYS120S

0.70-0.80

55

1.1

120

1.1

2.2

JCYS135S

1.0-1.5

75

1.5

135

2.2

2.2

JCYS160S

1.8-2.5

90

2.2

155

2.2

3.5

JCYS200S

3.0-4.0

132

2.2

195

3.0

4.5

Floating Fish Food Extruder
