Stainless steel peanut coating machine
Brief Introduction of peanut coating machine:
This machine is composed of machine body ,worm wheel box ,suger coating pan,heating device,fans,electric appliances and other major parts,it by motor through the triangle belt driving worm wheel,worm, driving suger coating pan rotating , driving under the influence of the centrifugal force, make the material rolling friction in the pot, achieve coated with sugar mixture, and making pill,and polishing effect.The peanut coating machine Can produce skin peanuts, chocolate peanuts, multi-flaored peanuts, beans, mouthful of fragrant etc.
Working Principle of peanut coating machine:
The main working parts of the machine is the angle of inclination of the rotating cylinders materials and hanging coated mateirals in rotating cylinders driven by the circumferential movement parabolic portfolio, to make it sticky follow uniform surface smoot, not adhesion between.
Debugging use of peanut coating machine:
1. Fixed equipment, the machine feel plus a rubber mat in order to facilitate reducing noise.
2. The power is turned on, check the direction of rotation is conducive to the operation, The general derection of the drum turning clockwise.
3. Check the barrel as well as the body withour missing tools, you can use it.
Parameters of peanut coating machine:
| Model | JC200 | JC300 | JC400 | JC600 | JC800 | JC1000 | JC1250 |
| Dia disc (mm) | 200 | 300 | 400 | 600 | 800 | 1000 | 1250 |
| Capacity(kg/time) | 1 | 2 | 5 | 15 | 30-50 | 50-70 | 80-150 |
| Rotate Speed | 46 | 46 | 46 | 36 | 36 | 32 | 28 |
| (r/min) | |||||||
| Power motor | 0.37 | 0.37 | 0.37 | 0.75 | 1.5 | 1.5 | 3 |
| (KW) | |||||||
| Power of fan | 0.075 | 0.075 | 0.075 | 0.06 | 0.12 | 0.12 | 0.18 |
| (KW) | |||||||
| Power of heat(KW) | 0.2 | 0.1 | 0.12 | 2 | 2 | 3 | 5 |
| Overall size(mm) | 500*350 *700 | 500*350 *700 | 550*400 *800 | 800*600 *900 | 1000*800 *1430 | 1100*1000 *1560 | 1250*1200 *1820 |
| Weight (kg) | 36 | 37 | 38 | 85 | 205 | 220 | 350 |
