Jiechang Rubber Hose for Concrete Pump

US$ 18,850 - 85,250 MOQ: 1 Unit

Key Specifications

Condition:

New

Power Type:

Electric

Place of Origin:

Henan, China

Zhengzhou Jiechang Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Power Type Electric

Place of Origin Henan, China

Brand Name JC

Model Number HBT40JC

Power(W) 45kw

Weight 3000kg

Dimension(L*W*H) 4500*1500*1800mm

Certification CE

Warranty 18months

After-sales Service Provided Engineers available to service machinery overseas

Specifications

rubber hose for concrete pump
1. Diesel or electricity
2. CE
3. 20-120CBM per hour
4. s-pipe design

the main oil pump adopt Japanese Kawasaki oil pump
two ways to convey concrete: high-pressure with small volume and low-pressure with large volume;
Y2 (famous brand) series engine, featured by low-noise, high torque and excellent start performance;
Hydraulic system adopts imported original valve form to control the concrete pump, improve the reliability a lot.
Italy MANULI high-pressure hose is used to ensure the security of hydraulic system, without leakage;
The distribution valve adopts the advanced S pipe valve system, good sealing performance; the structure is simple and reliable, and convenient replacement of the wearing parts.
High-absorption and optimize the hopper structure, improve the regional structure inside of the hopper which affects the suction performance;
Pumping fuel tank with an unique waterproof structure, and with the combination of discharging and blocking, so it has anti-emulsified activity;
Mixing blade with an unique design and few deal space so it can be adapted to a wide range of concrete formula;
The main electrical components are imported, they fully guarantee the electrical control system of high reliability;
Perfect maintainability and dismantling of all wearing parts are very convenient.
Introduction of electric proportional control technology, pumping displacement capacity can be adjusted without level
Main Parameters

Model		HBT15-08JC	HBT20-10JC	HBT25-10JC	HBT30-10JC	HBT35-11JC	HBT40-13JC	HBT60-11JC	HBT80-11JC
The theory of throughput (m3/h)	high pressure	7	9	14	20	16	22	37	50
The theory of throughput (m3/h)	low pressure	13	18	25	32	35	44	62	85
The theory of delivery pressure (Mpa)	high pressure	8	10	10	10	11	13	11	11
The theory of delivery pressure (Mpa)	low pressure	4.2	5.5	5.5	5.5	5.3	6.2	6.4	6.4
The delivery cylinder	Dia * route (mm)	Φ120 *550	Φ120 *900	Φ140 *1000	Φ140 *1000	Φ160 *1000	Φ180 *1200	Φ200 *1800	Φ200 *1800
Main power (kW)		22	30	37	45	45	55	90	110
Distribution valve		S pipe valve	S pipe valve	S pipe valve	S pipe valve	S pipe valve	S pipe valve	S pipe valve	S pipe valve
Maximum aggregate size(mm)	pipeΦ76	25	25	25	25
	pipeΦ89		30	30	30	30
	pipeΦ108					35	35
	pipeΦ133						40	40	40
	pipeΦ150							45	45
Concrete slump (mm)		100-230	100-230	100-230	100-230	100-230	100-230	100-230	100-230
Engine type		motor	motor	motor	motor	motor	motor	motor	motor
Hopper volume (m3)		0.34	0.36	0.4	0.4	0.4	0.5	0.6	0.6
Loading height (mm)		950	1000	1000	1000	1100	1100	1400	1400
Theoretical maximum transmission distance Vertical / level (meter)		120/450
Size LWH(mm)		3380 1270 1450	3400 1420 1620	3770 1420 1620	3770 1420 1620	3990 1670 1650	4300 1670 1680	5400 1882 1965	5400 1882 1965
Total weight(Kg)		1480	1680	2100	2200	2900	3200	5200	5600
