JC diesel concrete mixer with pump
the main oil pump adopt Japanese Kawasaki oil pump
two ways to convey concrete: high-pressure with small volume and low-pressure with large volume;
Y2 (famous brand) series engine, featured by low-noise, high torque and excellent start performance;
Hydraulic system adopts imported original valve form to control the concrete pump, improve the reliability a lot.
Italy MANULI high-pressure hose is used to ensure the security of hydraulic system, without leakage;
The distribution valve adopts the advanced S pipe valve system, good sealing performance; the structure is simple and reliable, and convenient replacement of the wearing parts.
High-absorption and optimize the hopper structure, improve the regional structure inside of the hopper which affects the suction performance;
Pumping fuel tank with an unique waterproof structure, and with the combination of discharging and blocking, so it has anti-emulsified activity;
Mixing blade with an unique design and few deal space so it can be adapted to a wide range of concrete formula;
The main electrical components are imported, they fully guarantee the electrical control system of high reliability;
Perfect maintainability and dismantling of all wearing parts are very convenient.
Introduction of electric proportional control technology, pumping displacement capacity can be adjusted without level
diesel concrete mixer with pump Main Parameters
Model |
HBT15JC |
HBT20JC |
HBT25JC |
HBT30JC |
HBT35JC |
HBT40JC |
HBT60JC |
HBT80JC |
|
|
The theory of throughput (m3/h) |
high pressure |
7 |
9 |
14 |
20 |
16 |
22 |
37 |
50 |
low pressure |
13 |
18 |
25 |
32 |
35 |
44 |
62 |
85 |
|
|
The theory of delivery pressure (Mpa) |
high pressure |
8 |
10 |
10 |
10 |
11 |
13 |
11 |
11 |
low pressure |
4.2 |
5.5 |
5.5 |
5.5 |
5.3 |
6.2 |
6.4 |
6.4 |
|
|
The delivery cylinder |
Dia * route (mm) |
Φ120 *550 |
Φ120 *900 |
Φ140 *1000 |
Φ140 *1000 |
Φ160 *1000 |
Φ180 *1200 |
Φ200 *1800 |
Φ200 *1800 |
Main power (kW) |
22 |
30 |
37 |
45 |
45 |
55 |
90 |
110 |
|
Distribution valve |
S pipe valve |
S pipe valve |
S pipe valve |
S pipe valve |
S pipe valve |
S pipe valve |
S pipe valve |
S pipe valve |
|
|
Maximum aggregate size(mm) |
pipeΦ76 |
25 |
25 |
25 |
25 |
||||
pipeΦ89 |
30 |
30 |
30 |
30 |
|||||
pipeΦ108 |
35 |
35 |
|||||||
pipeΦ133 |
40 |
40 |
40 |
||||||
pipeΦ150 |
45 |
45 |
|||||||
Concrete slump (mm) |
100-230 |
100-230 |
100-230 |
100-230 |
100-230 |
100-230 |
100-230 |
100-230 |
|
Engine type |
motor |
motor |
motor |
motor |
motor |
motor |
motor |
motor |
|
Hopper volume (m3) |
0.34 |
0.36 |
0.4 |
0.4 |
0.4 |
0.5 |
0.6 |
0.6 |
|
Loading height (mm) |
950 |
1000 |
1000 |
1000 |
1100 |
1100 |
1400 |
1400 |
|
|
Theoretical maximum transmission distance Vertical / level (meter) |
120/450 |
||||||||
Size L*W*H(mm) |
3380 *1270 *1450 |
3400 *1420 *1620 |
3770 *1420 *1620 |
3770 *1420 *1620 |
3990 *1670 *1650 |
4300 *1670 *1680 |
5400 *1882 *1965 |
5400 *1882 *1965 |
|
Total weight(Kg) |
1480 |
1680 |
2100 |
2200 |
2900 |
3200 |
5200 |
5600 |
|
diesel concrete mixer with pump pictures:
Load to container
Our company for Small Concrete pump/diesel concrete pump/mini concrete pump:
Pipes of Small Concrete pump/diesel concrete pump/mini concrete pump
JC machine welcome you.
