Home > Metallurgy, Mineral & Energy > Ceramic Material > Alumina Ceramics > Ceramic Super Intalox Saddles

Ceramic Super Intalox Saddles

Name: Ceramic Super Intalox Saddles
Brand: zhongying
SKU: 138694867
Availability: InStock

Ceramic Super Intalox Saddles thumbnail-1

Negotiable MOQ: 1 Ton (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Jiangxi, China

Type:

Ceramic Rings

Application:

Industrial Ceramic

Contact Supplier Request Quote Chat Now

Pingxiang Zhongying Packing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shengzhen shanghai and any port in china

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangxi, China

Type Ceramic Rings

Application Industrial Ceramic

Material Alumina Ceramic

Model Number 25-100

Brand Name zhongying

Specifications

1.20yearsProfessional Manufacturer of Ceramic super saddles.
Size:13mm, 25mm 38mm 50mm 76mm...

Ceramic super saddle has excellent acid resistance and heat resistance. It can resist to corrosion of various inorganic acids, organic acids and organic solvents except hydrofluoric acid, and can be used in high or low temperature conditions. Consequently the application range is very wide. It can be used in the drying columns, absorbing columns, cooling towers, scrubbing towers and actifier columns in chemical industry, metallurgy industry, coal gas industry, oxygen producing industry, etc.

Chemical composition

SiO₂	Al₂O₃	Fe₂O₃	CaO	K₂O+Na₂O
>70%	23-30%	<1%	<1-2%	<2-4%

Physical properties

Index	Value
Specific gravity(g/cm³)	2.25-2.35
Water absorption(%)	<0.5
Acid-resisting strength, %Wt. Loss (ASTMc279)	<4
Firing temperature(Degree C)	1280-1320
Softening point(Degree C)	>1400
Density(kg/m³)	2350

Geometric properties

Nominal Size		Approx. weight		Surface Area		Void Fraction (%)	Dry Packing factor (m^-1)
inch	mm	lb/ft³	kg/m³	ft²/ft³	m²/m³	Void Fraction (%)	Dry Packing factor (m^-1)
1"	25mm	40	645	79.5	260	77	570
1.5"	38mm	37.5	600	64	210	78	430
2"	50mm	35.6	570	42.8	140	79	277
3"	76mm	36	580	32	105	77	206
