Acid Ceramic Super Intalox Saddle

US$ 199.8 - 415 MOQ: 5 Cubic Meters

Key Specifications

Place of Origin:

Jiangxi, China

Type:

Ceramic Rings

Application:

Industrial Ceramic

Pingxiang Zhongying Packing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai shengzhen or any port you need

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangxi, China

Type Ceramic Rings

Application Industrial Ceramic

Model Number Ceramic intalox saddles

Brand Name zy

Specifications

Ceramic Intalox saddle can resist to corrosion of various inorganic acids, organic acids and organic solvents

Advantages of ceramic saddle:

1. Low Purchase Price
2. Lower Pressure Drop
3. High Thermal Shock Resistance
4. Meets all ASTM Standards

Application of Ceramic Super Intalox Saddle :

1. Regenerative Thermal Oxidizers
2. Acid Gas Scrubbers
3. Dryer Towers
4. Tail Gas Scrubbers
5. Impasse Towers

Chemical Property (%):

SiO2	Al2O3	Fe2O3	MgO	CaO	K2O	Na2O	Leachable Iron
68-72	19-23	≤1.0	0.6	0.6	3.5-4.5	0.1-0.3	0.01

Physical property of Ceramic super Intalox Saddle :

Specific Density	g/cm3	2.3-2.4
Water absorption	Wt %	≤0.5
Compression Strength	N/mm2	300-500
E-Modulus	GPa	60
Mohs Hardness	Scale	7-8
Specific heat, 20-100	J/kgK	840-920
Thermal Conductivity 30-100	W/mK	1-1.5
Coefficient of thermal expension	(20-600)10^-6K^-1	4.7
Heat Resistance		1000^oC
Acid resistance	% (DIN51102)	99.7%

Spec	DiameterxHeightxThickness mm	Surface area m2/m3	Void space m2/m3	Bulk pieces n/m3	Bulk weight Kg/m3	Packing factor m-1
25	40x20x3	216	0.78	76600	460	340
38	60x30x4	157	0.84	24600	450	190
50	80x42x6	88.4	0.81	8260	480	166
76	119x53x9	58.4	0.77	2430	500	127
