Specifications
1)20 years' professional manufacture2)Good quality and favorable price
3)Fast delivery and best service
4)ISO9001
Ceramic Tri-Y ring is a kind of ceramic tower packings which is belong to ceramic random packings. It has great advantage of acid-&heat-resistance. It can resist to corrosion of various inorganic acids, organic acids and organic solvents except HF acid, and can be used in high and low temperiture conditions.
Application: It be widely used in the tower of dry, absorbing, cooling, washing and recovery etc. in chemical, petrochemical and metallurgical industry.
Tri-Y ring Characteristic Indexes
| Name | Normal size | Diameter*Height*Thickness mm | Surface area m2/m3 | Free volume % | Bulk density kg/m3 | No.elements per/m3 | Packing factor m-1 |
| Tri-Y ring | Φ25 | 25*13*2 | 240 | 74 | 760 | 87000 | 390 |
| Φ38 | 38*20*3 | 160 | 75 | 740 | 27600 | 260 | |
| Φ50 | 50*30*4 | 138 | 75 | 745 | 10100 | 233 | |
| Φ80 | 80*50*9 | 90 | 70 | 710 | 1910 | 262 |
(We can also be designed and manufactured to meet the need of specific applications.)
Chemical composition
SiO2 |
Al2O3 |
Fe2O3 |
CaO |
K2O+Na2O |
>70% |
23-30% |
<1% |
<1-2% |
<2-4% |
Physical properties
Index |
Value |
Specific gravity(g/cm3) |
2.25-2.35 |
Water absorption(%) |
<0.5 |
Acid-resisting strength, %Wt. Loss (ASTMc279) |
<4 |
Firing temperature(Degree C) |
1280-1320 |
Softening point(Degree C) |
>1400 |
Density(kg/m3) |
2350 |
Our advantages:
1. We will supply with the best price in 24 hours.
2. We will supply with all information to u ,about package, weight etc.
3. Except the size we have now , We also can produce special size as u need.
4. We can communicate with u by Fluently and professional English .
5. If u are urgent, U can add my Skype: evelyn8711291 , or Call me at any time: 8615279918717.
6. For all products u buy, our product's warranty is for 2 years.
Our service at promise:
1.We promise to reply your inquiry relational our product within 24hours.
2.OEM&ODM service for your unique idea with absolutely convenient.
3.Experienced foreign trader with professional product knowledge.
4.Value on business credit , promise to protect your sales data, design,patent info.
