Home > Lights & Lighting > Bulb & Lamp > Ultraviolet Lamp > UVC Germicidal Amalgam Lamp

UVC Germicidal Amalgam Lamp

Name: UVC Germicidal Amalgam Lamp
Brand: Germicidal Lamp
SKU: 138665891
Availability: InStock

US$ 1 - 8 MOQ: 100 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

Germicidal Lamp

Model Number:

UVC

Contact Supplier Request Quote Chat Now

Lianyungang Jialei International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai qingdao lianyungang

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name Germicidal Lamp

Model Number UVC

Rated Power 42W

Voltage 220V

Product Description

UVC germicidal amalgam lamp

UV germicidal lamps with different bases, diameters, and lengths are available, which offer excellent efficiency. We supply two types of UV lamps, emitting UV-C wavelength at 253.7nm, ozone-free; while emitting UV-C wavelength both at 253.7nm and 185nm, ozone-generating.

Ultraviolet technology has been one of the most effective methods of water treatment and air purification. CREATOR UV lamp is the ideal solution for water/air disinfection application in a safe way, without using any chemicals.

The inner wall of the lamp tube is attached with high - tech mercury group fault, so that the ultraviolet intensity of the lamp is still maintained at a high level.

Amalgam UV lamp of ambient temperature wider adaptation range. This means that more for poor working environment, amalgam lamp can still play a more temperature performance.

The use of mercury technology, the intensity of the UV lamp can reach more than three times.

The average life span of the mercury lamp is more than 13000 hours.

There are two types :ozone and ozone type.

Application

Urban water use system

Municipal Wastewater Treatment

Swimming Pool

Central air conditioning and ventilation duct

Kitchen fume purification system

Ultra pure water degradation TOC system

254nm Amalgam vapor lamps Application:

l Municipal sewage disposal system

l Urban drinking water treatment system

l Swimming pool and spa water treatment system

l Ventilating duct and air-condition treatment system

254nm Amalgam vapor lamps Application:

l Remove kitchen lampblack purification

l Ventilating duct and air-condition treatment system

l UVC cleaning, reducing the application of TOC

l Swimming pool and spa water treatment system

l Ultra-pure process water treatment system

(for semiconductor, pharmaceutical, cosmetics companies)

Type	Tube Diameter (mm)	Length (mm)	Power (W)	Voltage at50/60HZ (V)	Current (A)	UV output 254um		Life (H)
Type	Tube Diameter (mm)	Length (mm)	Power (W)	Voltage at50/60HZ (V)	Current (A)	(UW/CM2)	(W)	Life (H)
T5
GPHA357T5L	15	357	42	36	1.2	110	11	13500
GPHA843T5L	15	843	105	88	1.2	320	35	13500
GPHA1000T5L	15	1000	127	107	1.2	370	42	13500
GPHA1554T5L	15	1554	190	164	1.2	500	68	13500
T6
GPHA357T6L	19	357	57	32	1.8	130	13	13500
GPHA843T6L	19	843	130	71	1.8	400	43	13500
GPHA1000T6L	19	1000	150	84	1.8	460	52
GPHA1554T6L	19	1554	240	134	1.8	600	84	13500
GPHHA357T6L	19	357	65	31	2.1	140	14	13500
GPHHA843T6L	19	843	172	85	2.1	490	54	13500
GPHHA1000T6L	19	1000	207	99	2.1	570	65	13500
GPHHA1554T6L	19	1554	320	154	2.1	750	105	13500
T8
GPHHA1510T8L	25	1510	250	83	3.1	650	90	13500
T10
GXA1500T10L	32	1500	270	75	3.8	650	93	13500
GPHHA1310T10L	32	1310	400	82	5.0	1050	130	13500
GPHHA1554T10L	32	1554	470	95	5.0	1160	157	13500
GPHHA1554T10L	32	1554	500	90	5.5	1300	165	13500
