China SH100hp Tractor

China SH100hp Tractor thumbnail-1
China SH100hp Tractor photo-1
US$ 12,500 - 18,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Linyi Shunkai International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 100hp
Certificate Other, ISO9001
Brand Name SH
Model Number SH1004
Place of Origin Shandong, China
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Shuhe Brand
100hp 4WD tractor
Good quality and best service

Equipped with famous&durable gear box and engines ,

working with different agricultural tools can satisfy user's different demand .



 we have stock now!

can be Shipped at once!

Tractor Model

SH-1000

SH-1004

Tractor Type

4X2

4X4

Calibration Traction (KN)

≥18

≥21.3

Dimension(MM) LXWXH

(4010-4250)X(1900-2100)X(2450-2900)

Wheelbase(MM)

2195

2195

Tread(MM)

Front Wheel

1380-1680

1600-1620

Rear Wheel

1600-1650

1600-1650

Structural

Mass(KG)

Without Cab.

3100

3500

With Cab.

3350

3750

Theoretical Running Speed (KM/H)

(Optional Creeper Gear)

Front Gear

(8 Gear):

2.41/3.75/6.01/8.38/10.47/16.29/26.06/36.37

Reverse Gear

(4Gear):

3.24/5.04/8.06/11.25

Power Engine Type

Rated Speed R/Min

Vertical, Water Cool, Four-stroke, Direct Injection Combustion /2300rpm

Rated Power (KW)

73.5

73.5

Clutch

Dry-type/Single-Plate/Double-Acting/Constant Conjunction

Gear Box

4X(2+1) Clutch Shift

Rear Axle

Main Drive

Spiral Cone Arc Gear Spokes

Differential

Planetary Bevel Gear Type

Differential Lock

Engagement Nested

Final Drive

Planetary Reducer

Front Drive Axle

Shaft

         /

Mid-mounted Drive Shaft

Front Main Drive

/

Spiral Bevel Gear Type

Front Differential

/

2 Planetary Bevel Gear, Closed

Front Final Drive

/

Single-stage Planetary Gear

Steering System Type

All Hydrostatic Power Steering

Brake

Wet Double Plate Disc Brake

Tyre Type

Front Tyre

6.5-20

11.2-24

Rear Tyre

16.9-34

16.9-34

Tyre Pressure

Front Tyre

220-250

110-140

Rear Tyre

110-140

110-140

PTO Type/ Speed

Independent Type 760/1000 (540/1000 is also available)

PTO Power (KW)

62.5

Hydraulic Lifting System

Partial Separated Type; Separated Type

Suspension Mechanism Type

Rear Three-Point Suspension (Optional External Mounting Lifting Type)

Lift-off Weight (At 610MM)

≥17.7



China SH100hp TractorChina SH100hp TractorChina SH100hp TractorChina SH100hp TractorChina SH100hp Tractor
