High Output Grain Dryer / Small Grain Dryer / Rice Grain Dryer

High Output Grain Dryer / Small Grain Dryer / Rice Grain Dryer photo-1
US$ 10,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
grain dryer
Use:
grain dryer
Certification:
ISO90001
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Tianjin/Shanghai as client's request
Delivery Detail:
Delivery time depends on order quantity.
Type grain dryer
Use grain dryer
Certification ISO90001
Place of Origin Henan, China
Brand Name maisheng
Model Number 5H-15
Condition New
After-sales Service Provided Engineers available to service machinery overseas

  grain dryer

 We have total 3 types of grain dryers,one type is small continus grain dryer,very mini.There are 4 models of this mini grain dryer.The detsil as follows:

1.  Simple type drying

capacity : 5ton/day,

capacity of the drying silo: 400kg.

power : 10KW
Weight : 150kg

Dimension:1.2X1x2.1m.



2.Coal fuel type



capacity : 8ton/day,



capacity of the drying silo: 750kg.



power : 10KW
Weight : 300kg



Dimension:1.5X1.2x2.3m.




3 Stalk fuel type



capacity : 10ton/day,

capacity of the drying silo: 1000kg.

Weight : 300kg

 Dimension:2X1.2x3.5m.





4.capacity of the drying silo: 3000kg.

Dimension:2X1.2X5m



The second type is tower type.

This  grain dryer have 15ton/batch,20ton/batch and 30ton/batch,we can combine the dryers optional. such as we can combine two sets 15ton dryers to up to 30ton capacity,combine one set 15ton and one set 20ton dryer to up to 35ton capacity,combine two sets 30ton dryers to up to 60ton capacity and so on.

Technical data of grain dryer:
Model5H-15  grain dryer
GrainDimension2530*2780*7821
Heating wayIndirect
IgnitionAutomatic/manual
Temp of hot wind60-75°C
Highest temp of grain32-40°C
Grain cycle time45min
Drying rate0.7-1.0%
Processing capacity1000-1500kg/h
DryerCapacity10.5ton
Power of elevator1.5KW
Exhaust fan5.5KW
Air blower2.2KW
Chaff Furance

Dimension1380*2950*2200mm
Dimension of exchanger1270*1*1670*1230mm
Grate area0.47m2

 The third type is Mobile grain dryer,if you need,we can provide information.

 Pictures of small continus grain dryer
High output grain dryer / small grain dryer / rice grain dryerHigh output grain dryer / small grain dryer / rice grain dryerHigh output grain dryer / small grain dryer / rice grain dryerHigh output grain dryer / small grain dryer / rice grain dryer
 Pictures of tower grain dryer
High output grain dryer / small grain dryer / rice grain dryerHigh output grain dryer / small grain dryer / rice grain dryerHigh output grain dryer / small grain dryer / rice grain dryerHigh output grain dryer / small grain dryer / rice grain dryerHigh output grain dryer / small grain dryer / rice grain dryerHigh output grain dryer / small grain dryer / rice grain dryer

Pictures of mobile grain dryer
High output grain dryer / small grain dryer / rice grain dryerHigh output grain dryer / small grain dryer / rice grain dryerHigh output grain dryer / small grain dryer / rice grain dryer
