Help Center7C Series Agricultural Trailer(0.5-15t)
Related Products
-
Tractor Trailer for SaleUS$ 4,300 - 5,000MOQ: 5 Sets -
Farm Large Trailer for SaleUS$ 4,300 - 5,000MOQ: 5 Sets
-
Tractor Mounted Heavy TrailerUS$ 4,300 - 5,000MOQ: 5 Sets
-
Large Trailer Matched With TractorUS$ 4,300 - 5,000MOQ: 5 Sets
-
Light Duty 20-55hp Farm Tractor Trailer Load 3000kg / 3 TonsUS$ 1,350 - 1,650MOQ: 3 Sets
Specifications
The 7C series farm trailer has vairous type from 0.5T to 15T. The product has reasonable structure; beautiful appearance, encono7C series agricultural trailer(0.5-15t)
The 7C series farm trailer has vairous type from 0.5T to 15T. The product has reasonable structure; beautiful appearance, enconomic and durable and can match various types of tractors.
The 7C series agriculture divide into the suspension type and half suspension type with the trailer, self-discharging and not self-discharging and so on.The load-carrying capacity matching with each kind of 8~120 horsepower tractor is suitable for road and the field transportation.
More information:
Model |
Carriage Dimension (mm) |
Outside Dimension(mm) |
Load (kg) |
Dead Weight |
Tyre type/ tyre quantity |
Unload form |
Matched power (hp) |
7CX-3 |
3400*1700*460 |
4400*1750*1980 |
3000 |
980kg |
7.00-16/4 |
Hydraulic dump |
25-40 |
7CX-4 |
3800*1700*460 |
5200*1750*2000 |
4000 |
1200 kg |
7.50-16/4 |
Hydraulic dump |
25-40 |
7CX-5 |
3950*2190*550 |
5550*2250*2170 |
5000 |
1700 kg |
8.25-16/4 |
Hydraulic dump |
40-60 |
7CX-6 |
4500*2150*550 |
6200*2200*2300 |
6000 |
2050 kg |
9.00-16/4 |
Hydraulic dump |
50-90 |
7CX-8 |
5500*2150*550 |
7300*2200*2500 |
8000 |
2500 kg |
9.00-20/4 |
Hydraulic dump |
60-100 |
7CX-10 |
6000*2150*550 |
7800*2200*2500 |
10000 |
3000 kg |
8.25-16/8 |
Hydraulic dump |
80-100 |
7CX-12 |
6500*2200*500 |
8300*2200*2500 |
12000 |
3400 kg |
9.00-20/8 |
Hydraulic dump |
80-100 |
Pictures:
