carbon steel | alloy steel | stainless steel | aluminum Fire Extinguisher

Specifications

ISO9001:2008
We can make different type of Fire Extinguisher according to customer's special inquiry

Dry Powder  Fire Extinguishers



Features



This product is charged with ammonium phosphate powder extinguishing agent and employs nitrogen ad

driving gas. It is used to put out fires of solid organic matter, oil, flammable liquid, gas and electric facilities

in the initial stage. It is easy to operate and enjoys fast fighting and intermittent discharge. It is widely used

in plants, warehouses, institutions , schools, marketplaces, hotel, vehicles, vessels, etc.





Specification



Models	Suitable Areas	Operating Temperature(°C)	Fire Fighting Class	Weight of  Charged Chemical(kg)	Nitrogen Pressure(MPa)	Time of  Discharge(s)	Shooting Range (m)	Jetting Residual Rate(%)	Jetting Delay Time
MFZL1	ABCD	-20°C-+55°C	1A2BC	1±0.05	1.2	8	3	15	5s
MFZL2	ABCD	-20°C-+55°C	1A3BC	2±0.06	1.2	8	3	15	5s
MFZL3	ABCD	-20°C-+55°C	2A5BC	3±0.09	1.2	13	3	15	5s
MFZL4	ABCD	-20°C-+55°C	2A10BC	4±0.08	1.2	13	3	15	5s
MFZL6	ABCD	-20°C-+55°C	3A14BC	6±0.10	1.2	13	3.5	15	5s
MFZL9	ABCD	-20°C-+55°C	4A22BC	9±0.16	1.2	13	4.5	15	5s



Packing and Storage
Packing with paper cartons, prohibited to transport with the products upside-down, and hanging in ventilated and dry places of from -10°C to 45°C.
