MARINE Brass Water Stop Valve
Marine Brass Water Stop Valve
Gate valve is a valve that the valve plate moves along the vertical direction in the pipeline.
Brass gate valve : BIMAN brand
Specification: Non rising stem, solid wedge, full bore, screw ends
Manufactured according to BS 5154 : 1991 Standard
Green colour handwheel
Manufactured according to BS 5154:1991 Standard
BS 21 / ISO 228-1-2000 Standard threads
Max working pressure 10 bar
Max working temperature 120 °C
MATERIAL
PARTS |
MATERIAL |
Body |
Brass |
Disc |
Brass |
Gland packing |
PTFE |
Bonnet |
Brass |
Gland nut |
Brass |
O-ring |
Teflon |
Gland ring |
Brass |
Lock nut |
Brass |
Stem |
Brass |
Hand wheel |
Cast iron |
Name plate |
Aluminium |
Wheek nut |
Inox stainless steel |
DIMENSION
Valve size inch |
½ 15 |
¾ 20 |
1 25 |
1 ¼ 32 |
1 ½ 40 |
2 50 |
2 ½ 65 |
3 80 |
4 100 |
ØA (mm) |
54 |
54 |
60 |
71 |
71 |
77 |
110 |
120 |
150 |
B (mm) |
75 |
85 |
90 |
105 |
114 |
138 |
166 |
190 |
226 |
C (mm) |
42 |
44 |
52 |
56 |
62 |
66 |
80 |
89 |
110 |
ØD (mm) |
15 |
19.5 |
24.5 |
30 |
35 |
46 |
60 |
72 |
90 |
E (mm) |
9.5 |
12 |
13 |
14.5 |
15 |
16 |
20 |
22.5 |
27 |
Sw (mm) |
26 |
32 |
38 |
48 |
54 |
67 |
83 |
94 |
125 |
Weight (g) |
270 |
330 |
450 |
630 |
830 |
1380 |
2200 |
2840 |
5600 |
Pcs/ box |
10 |
10 |
6 |
4 |
4 |
2 |
1 |
1 |
1 |
