Help CenterYL61C-RIDE-ON HYDRAULIC VIBRATORY ROLLER
Related Products
Specifications
1.vibratory roller passed CE certificate2.Honda/Perkins engine
3.hydraulic steering
4.hydraulic drive
5.hydraulic vibration
YL61C-RIDE-ON HYDRAULIC VIBRATORY ROLLER
The machine is mainly used to compress on the asphalt, sand soil and gravel. It is also used to compress on track in the school and planish the lawn. This is the latest model of light duty rollers in the domestic. Famous brand engine, excellent performance, easy to start-up;
Famous brand variable pump, fixed displacement motor, steppless speed, easy to change direction;
Hydraulic diversion, efficient and convenient;
The whole machine could be controlled by instrument panel;
NSK bearing, excellent performance;
Comfortable driving seat; Streamline surface, more beautiful;
Plastic treated, anti-rust, anti-corrosion and beautiful.
Have passed CE certificate.
| TYPE | YL61C |
| RUN | |
| SPEED | 0-12KM/H |
| TURING RADIUS | 2600MM |
| CLIMBING CAPACITY IN THEORY | 40% |
| COMPACTION | |
| STATIC LOAD FORWARD/BACK | 118/110N/CM |
| NOMINAL AMPLITUDE | 0.5MM |
| VIBRATION FREQUENCY | 60HZ |
| EXCITING FORCE | 2*30KN |
| WATER TANK VOLUME | 220L |
| WORKING | |
| DRIVE | Variable plunger pump,constant displacement hydraulic motor |
| VIBRATION | Gear pump,Gear motor |
| TURNING | Redirector,hydraulic ram |
| Stop braking | Hand draw and friction |
| ENGINE | |
| MODEL | Pekins 403D-15 |
| TYPE | Disel engine,water-cooled,4stroke,three cylinder |
| POWER | 32.2hp/2800rpm |
| Fuel tank volume | 40L |
| Lubricant L | 3.8L |
| Fuel consumption | 281g/kWh |
| Dimension | |
| Width of steel wheel | 1200mm |
| Diameter of steel wheel | 700mm |
| Tread | 1730mm |
| Total lehgth | 2445mm |
| Total width | 1280mm |
| Total height | 2703mm |
| Packing size | 2565*1380*1970mm |
| Weight | |
| Working weight | 2850kg |
