Farfly Horizontal Wet Bead Mill

Farfly Horizontal Wet Bead Mill photo-1
Farfly Horizontal Wet Bead Mill photo-2
Farfly Horizontal Wet Bead Mill photo-3
US$ 25,000 - 27,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Sand Mill, disc type bead mill
Product Type:
Other, wet bead mill
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, Sand Mill, disc type bead mill
Product Type Other, wet bead mill
Place of Origin Shanghai, China
Brand Name FARFLY
Model Number FSP bead mill
Voltage 220V/380V
Power(W) 30kw
Dimension(L*W*H) 1600*700*1650
Weight 550kg~2000kg
Certification CE/ISO9001
Warranty 3 year
After-sales Service Provided Engineers available to service machinery overseas
Product Description



1. Product Name:

Farfly horizontal wet bead mill



2. Product Descrption :

Farfly horizontal wet bead mill--Germany technology: static centrifugal discharging devices, large discharge area with high output.

Adopts double mechanical seal,the lubricating liquid dissolved with material,safe and reliable.

Grinding area made of special anti-wearing alloy material ensures long service life.

Intelligent double mechanical seals: the technology of Germany mechanical, the imported- fluorine sealing rings can be anti-eroded different solvents.

3. Advantage of Farfly horizontal wet bead mill

Cooling efficiency: the double helix segmented more advantageous to the exchange energy. Cooling efficiency is 2 times than ordinary types.

Grinding efficiency than ordinary type: increased by more than 30%, the combination of the distributor can rapidly improving dispersion efficiency. The grinding media can choose superfine grinding medium.



3. Technical specification

Type/Parameter

Motor power

(Kw)

Barrel capacity

       (L)

Pump flux

(L/min)

Cooling water

(m3/h)

Production capacity

(L/h)

Milling medium(

mm)

FSP-30

22

30

2~17

1.5~2

80~600

0.8~2.0

FSP-50

30

50

3~22

2~2.5

100~800

0.8~2.0

FSP-60

30

60

3~22

2~2.5

120~1000

0.8~2.0

FSP-100

55

100

5~40

2.5~3

200~1500

0.8~2.0

4. After Sales Service

The above machine which we supply it to you, we can give you one years after sales warranty, we can also send our engineer to you factory to install this equipment and train your staff, but the Buyer should pay the round air ticket cost and arrange the hotel accommodation as well as the meals for Seller’s engineer. We will send some free set of spare parts for you change it.

5. Payment terms:

30% deposit by T/T before production, 70% balance should be paid by T/T before shipment. but we also accept L/C.

6. Package:

Standard wooden Case Packing

7.Shipment terms:

We usually take FOB, but we can also accept EXW,CIF,CNF.



8. Photos for reference



Farfly horizontal wet bead mill

Farfly horizontal wet bead mill

 Farfly horizontal wet bead millFarfly horizontal wet bead millFarfly horizontal wet bead millFarfly horizontal wet bead millFarfly horizontal wet bead millFarfly horizontal wet bead millFarfly horizontal wet bead millFarfly horizontal wet bead mill
