Home > Products > Grinding mill > FZS Conic pin-type horizontal sand mill/bead mill/grinding mill/ball mill
FZS Conic pin-type horizontal sand mill/bead mill/grinding mill/ball mill
- 49 Set / Sets per Month
- Shanghai
- T/T
Product Details
Condition: | New | Type: | Sand Mill | Product Type: | Other, coating, ink |
Place of Origin: | Shanghai, China | Brand Name: | FARFLY | Model Number: | FZS |
Voltage: | 220~460V/ 3phase | Power(W): | 18.5~22kw | Weight: | 1050/ 1150kg |
Certification: | CE / UL /ISO9001 | Warranty: | 1~4 years | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Horizontal sand mill, bead mill, conical horizontal sand mill
Main characters:
--Adopting power compression designed principle ,high compression kenetic energy can be received as material come in;
--Adopts wearing proof alloy main body with taper cavity,can produce prodcuts of high quality;
--Adopts main body with variable volume ,filling factor of milling medium can be turned at will,can meet various requirements;
--Adopts double mechanical seal,the lubricating liquid dissolves with material,safe and reliable;
--Double cooling system of main body and axes,with strong ability of cooling.
Application areas:
Offset printing ,fluorescence,uv,embossing plate pringting ink,concentration color paste and other coating with medium and high viscosity.
Technical specification:
Type/Parameter | Motorpower KW | Fluk L/h | Coolingwater cost M3/h | Barrelcapacity L | Dimension mm | Weight KG |
FZS-5 | 18.5 | 30~50 | 1.3 | 5 | 1650*670*1780 | 1050 |
FZS-25 | 22 | 80~800 | 2 | 20 | 1700*670*1880 | 1150 |
