Drill Motor LMMGROUP Traction

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Any Chinese seaport
Payment TermsT/T Money Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	LMMGROUP	Model Number	LMMGROUP
Usage	Other	Certification	CCC
Type	Tubular Motor	Torque	8033
Construction	Series Wound	Commutation	Brush
Protect Feature	Explosion-proof	Speed(RPM)	965
Continuous Current(A)	1150	Output Power	800
Voltage(V)	750

Product Description

Specifications

Equal to GE 752 series drilling motor, high torque, wide speed in constant power district. Used for mud pump, rotary table,etc.

Type DC Drill Motor

Oilfield DC motor are high power series excited DC motor developed for electric drive oil drilling machine. The international advanced technology has been adopted in it such as Kapton insulation process, main pole coils formed by hot pressing, pressed and welded frame, spiral slot of commutator, reacting brush holder, wire banding etc. The main features of the motors are as follows: plus pressure explosion-proof, high current, large torque, wide range constant power speed regulating, free maintenance, high universality, efficiency and reliability. Their outline installation dimension is strictly in accordance with that of imported DC oil drilling motor. The oil drilling motor can be used instead of the imported one. They can function as slurry pump motor, rotary table motor and winch motor of DC electric drive drilling machine. The motors are divided into two types,according different position of terminal (see from drive end) .

Rated power	800Kw
Rated voltage	750V
Rated current	1150A
Rated rotating speed	970r/min
Rated efficiency	93%
Rated torque	8033.7N.m
Max. current	1600A
Max. torque	12206.4N.m
Max.rotating speed	1500r/min
Exciting	series
Insulation class	H/H
Cooling	Forced air
Protection class	Plus pressure explosion-proof
Mass	3200Kg
