China SL30 Brand best price Hydraulic hammer
- 100 Unit / Units per Month
- China Main Port
- T/T
- CAT HOSE AS 363-8127 3638127 Caterpillar genuine
- Advanced Portable Water Well Drilling Rig 760kg Mud Drilling Capability
- Water Well Drilling Machine With 150 Meters Depth And Large Hole Diameter
- 220V / 380V Water Well Drilling Machine / HZ 200 M Mine Borehole Rock Drill Rig
- High Efficiency Water Well Drilling Rig XY-3 300m Depth For Geothermal Exploration
- Auto Balancing Turnover Spreader Beam for Car Frame/Chassis/Trailer/Flatbed Turning
Product Details
Model Number: | SL30 |
Product Description
Specifications
Hydraulic hammerExcellent quality and reasonable price
Prompt dlivery
Good appearance
Hydraulic hammer
Technical Parameters:
Hammer | Drop Weight | Stroke | Frequency | Max Power | Basic Weight | Length | Power Pack Type |
Kg | mm | b/min | knm | kg | M | Kw | |
SL20 | 3000 | 20-1200 | 34-100 | 20 | 4100 | 3.575 | 71 |
SL30 | 5000 | 20-1200 | 33-100 | 30 | 5400 | 4.575 | 71 |
CX40 | 5000 | 20-1200 | 33-100 | 40 | 5200 | 4.022 | 71 |
CX50 | 5000 | 20-1200 | 33-100 | 51 | 6100 | 4.022 | 127 |
CX60 | 7000 | 20-1200 | 33-100 | 60 | 7600 | 4.975 | 127 |
CX75 | 7000 | 20-1200 | 33-100 | 71 | 8700 | 4.975 | 127 |
CX85 | 9000 | 20-1200 | 33-100 | 83 | 9800 | 4.975 | 127 |
CX110 | 11000 | 20-1200 | 33-100 | 106 | 12050 | 5.475 | 250 |
CG180 | 11000 | 20-1500 | 31-100 | 180 | 17240 | 7 | 250 |
CG210 | 14000 | 20-1500 | 31-100 | 210 | 20430 | 7.45 | 250 |
CG240 | 16000 | 20-1500 | 31-100 | 240 | 22760 | 7.75 | 250 |
CG270 | 18000 | 20-1500 | 31-100 | 270 | 25110 | 8.05 | 250 |
CG300 | 20000 | 20-1500 | 29-100 | 300 | 27460 | 8.35 | 250 |
CGL370 | 250000 | 20-1500 | 32-75 | 370 | 34650 | 7 | 390 |
CGL440 | 300000 | 20-1500 | 32-75 | 440 | 41150 | 7.465 | 450 |
CGL520 | 350000 | 20-1500 | 32-75 | 520 | 46650 | 7.93 | 520 |
Feature
Reliability:
BSP CG hammer draws on BSP`s 100 year experience. The range has been extensively site tested, easy to operate and maintain.
Controllability:
The Proven BSP remote control panel, provides the CG range with an infinitely variable stroke and blow rate. The precise delivery of energy to the pile, enables the contractor to maximize production rates, avoid pile damage and the problems of the pile runaway.
Versatility:
The CG range of piling hammer is designed for driving a variety of bearing piles including steel tube, combi piles, H sections and reinforced/pre stressed concrete piles,also suitable for driving raked(batter)piles.
Economical:
The relatively low hydraulic demand of the CX actuator reduces fuel consumption.Low hydraulic power pack requirement.
Monitor:
Total control of hammer stroke and blow rate.
Environmentally Friendly:
Low exhaust emissions,low noise emissions with improved dolly material
