Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Concrete Machinery > Asphalt Concrete Mixing Plant XCMG Shantui Changlin XG SANY Zoomlion SDLG LQC160 Mixing Plant
Asphalt Concrete Mixing Plant XCMG Shantui Changlin XG SANY Zoomlion SDLG LQC160 Mixing Plant
US$ 10,000 - 60,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
XCMG
Model Number:
LQC160
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Asphalt Concrete Mixing Plan TXCMG Liugong Changlin Mixing Plant LQC240US$ 10,000 - 60,000MOQ: 1 Unit -
Asphalt XCMG XG SDLG Shantui Zoomlion Liugong Tiangong Concrete Mixing Plant LQC320US$ 10,000 - 60,000MOQ: 1 Unit
-
Cost-effective China Concrete Mixer JZC350-ESUS$ 1,000 - 3,000MOQ: 1 Unit
-
Good Brand Concrete Mixer JZC350-EL Made in ChinaUS$ 1,000 - 30,000MOQ: 1 Unit
-
Erengy Saving CHUANGXIN Concrete Mixer JZC350 With Good QualityUS$ 1,000 - 30,000MOQ: 1 Unit
Brand Name
XCMG
Model Number
LQC160
Specifications
Optimized flights and lifter design allows system to achieve a more uniform heating Concrete Mixing PlantFull-open design
Du
Concrete Mixing Plant
| Rated production capacity (with 5% moisture content) | 160t/h |
|---|---|
| Cold aggregate bin | 5 bins/40m3 |
| Output capacity | 180t/h |
| Drying drum specification | Φ2.2m×8.0m |
| Capacity (with 5% moisture content) | 180t/h |
| Bag filter: model/filtering area | PFK468/836 |
| Emission standard | ≤20mg/Nm3 |
| Screening-weighing-mixing system | |
| Vibrating screen | 5 layers/24m2 |
| Hot aggregate bin | 5/40t |
| Asphalt weight | 0~500Kg (automatic injection) |
| Mixing tank capacity | 2250kg |
| Mixing Cycle | 45s |
| Filler silo capacity | 2×20t |
| Asphalt tank capacity | 2×50,000L |
| Heat conduction oil furnace | 500,000kcal/h |
| Finished product bin capacity | 200t,120t,80t |
| System control: manual/semi-auto/auto·Chinese operating system·1000 recipes storage | |
| Measuring accuracy | |
| Aggregate | ≤±0.5% |
| Filler | ≤±0.3% |
| Asphalt | ≤±0.25% |
| Total installed power | 495kW |
| |
