LT207G Singal Drum 7T Hydraulic Vibrating Road Roller

LT207G Singal Drum 7T Hydraulic Vibrating Road Roller thumbnail-1
LT207G Singal Drum 7T Hydraulic Vibrating Road Roller thumbnail-2
LT207G Singal Drum 7T Hydraulic Vibrating Road Roller photo-1
LT207G Singal Drum 7T Hydraulic Vibrating Road Roller photo-2
US$ 20,100 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Single Drum Roller
Travel Speed:
2.2/4.7/15 Km/H
Contact Supplier Request Quote Chat Now
Henan Light Industrial Products Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Single Drum Roller
Travel Speed 2.2/4.7/15 Km/H
Grade Ability 25%
Brand Name OEM
Model Number LT207G
Power(W) 42 KW
Dimension(L*W*H) 5010*1880*2570 MM
Weight 7000 KG
Certification QS, CE
After-sales Service Provided Engineers available to service machinery overseas

LT207G singal drum mechanical driving hydraulic vibrating road roller

Product Description
Standard configuration
1.Mechanical driving,hydraulic vibrating,articulated steering
2.Engine: adopt 498 direct spray diesel engine
3.Drive axle: special drive axle of road roller
4.Front and rear wheel with scraper and electrical sprinkler
5.With a ordinary cab
6.Tire: Surface of the tire light

Optional configuration

1.Tire: tire with tread,for aspalt conrete compression utility and practical basal pressure.



Main Technical Parameters

MODEL Unit LT207G
Operating mass kg 7000
Static linear load N/cm 215
Vibration amplitude mm 0.4
Vibration frequency Hz 43
Centrifugal force KN 70
Travel speed km/h 2.2/4.7/15
Grade ability % 25
Turning radius mm 5000
Overall dimension mm 5010×1880×2570
Vibration round width mm 1700
Wheelbase mm 2750
Ground clearance mm 320
Diesel power kw 42
Diesel model   498BG
Diesel speed r/min 2200
Tire model   12.00-24.16



LT207G singal drum 7T hydraulic vibrating road roller

LT207G singal drum 7T hydraulic vibrating road rollerLT207G singal drum 7T hydraulic vibrating road roller





Main Features

1.Hydraulic vibration,great centrifugal force and high compactness.
2.Mechanical travel,pneumatic tyre drive,three speed changes both forward and backward and high speed travelling.
3.Articulated frame,hydraulic steering,small turning radius and flexible drive.
4.Full anti-corrosive spray water system,large capacity water tank,electrical pressurized spinkler and unique nozzle design which covered all of the steel and pneumatic wheel.

5.Two sets of brake devices,a hand brake and foot pedal brake,assure the machine's safety and dependability.
6.Both clutch and foot pedal brake system are adopted hydraulic power and saving manpower to operate.







Packaging & Shipping



Fixed it in the container with the steel wire rope and the fasten tie



Our Services

Engineers available to service machinery oversales
