Nitto UHMWPE Heat-resistance Adhesive Tape No. 443

Name: Nitto UHMWPE Heat-resistance Adhesive Tape No. 443
Brand: Nitto
Price: Negotiable

FOB Price

Negotiable / Roll

1 Roll(Min.Order)

Supply Ability 3000 Roll / Rolls per Month
Port Shenzhen/ Shantou
Payment Terms:Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Material:	PE	Use:	Masking	Adhesive Side:	Single Sided
Adhesive:	Silicone	Adhesive Type:	Hot Melt, Pressure Sensitive
Design Printing:	No Printing	Place of Origin:	Japan	Brand Name:	Nitto
Model Number:	443

Product Description

Nitto UHMWPE Heat-resistance Adhesive Tape No. 443

It has excellent resistance to impact strength, wear resistance and self lubrication film adhesive tape.

Summary:

Pressure sensitive adhesive tape No. 443 is based on UHMWPE film (No. 440) as the basic material, together with stripping liner. Compared with the other adhesive tape which is use resin film, its impact resistance strength, wear resistance and self lubricity is better.

Characteristics:

Resistance to impact strength greatly, is also excellent in plastic material.
It has excellent wear resistance.
It possesses excellent self lubrication performance.
To except part of the inorganic species of strong acid and aromatic solvents, this tape has the stable chemical resistance
It has excellent water absorption performance and the moisture absorption performance

Purpose	1.Bottle for injection machine and label pasting machine, automatic machine sales and so on the smooth surface and the guide sleeve
	2.Used in all kinds of conveying machinery conveyer belt guide sleeve cover and mesa
	3.For a variety of film and paper packaging mechanical forming mandrel sleeve
	4.Used for gasket lining
	5.Used for lining of various kinds of hopper feeder storage
	6.Sliding surface material is used in home appliances and automatic sliding
	7.The sliding surface materials for the photocopier
	8.Used for fiber machine slip sliding surface material
	9.Used for binding machine slip sliding surface material
	10.Used for the slip plane of the printing press slide material

Standard Size:

Article No.	Thickness[mm]	Width[mm]	Length[m]
NO.443	0.10, 0.13, 0.20, 0.25, 0.30	300, 350	10, 30,50
No.443(Black)	0.40,0.50	300, 350	10, 30

[Note] The thickness of No. 443, No. 443 (black) is the thickness of the base material.

General characteristic:

Item	Unit	No.443
Item	Unit	White	Black
Base material thickness	mm	0.13	0.13
Total Thickness	mm	0.30	0.30
Strength of Extension	MPa	55.3	51.3
Percentage elongation	%	400	380
Stripping adhesive force (To the stainless steel plate)	N/20mmWidth	17.1	14.5
Surface resistance	Ω	10¹⁶	10⁶
Copper corrosion	-	Will change color	Will change color

[Note] The data above are only for the measurements of a case, not a guarantee value.
