DT-05B Rechargeable Tachometer Stroboscope with Battery
Technique Parameters:
Place of Origin: China
Brand: Wingtai
Model No. : DT-05B
Type : With Battery
Trigger frequency range: 50~20000 times / min.
Power: AC 110V,60HZ Or AC 220V 50HZ ;
Ambient light illumination: < 10000 Lux
External trigger signal range: 5~12V pulse signal
Features:
1. External trigger or Internal trigger methods are optional.
2.When it is external trigger working mode,it can track the image automatically.
3. Stop flashing automatically function.
4. DT-05B and DT-07B is chargeable muti function lithium stroboscope, can charging intelligently and quickly.When charging, you need to connect 220V power line, then intelligent charging circuit starts to work, it can charge over 95% into Li battery within 30 minutes and then get into slow filling state. It will stop charging when its batteries are full so that it can protect the batteries using life. It can be used withou batteries, only need to connect the power line. It is an ideal and essential tool.
5.Beautiful shape and lighter, easy to carry; anti-static, simple operation,cost-effective advantages.
Application :
Widely used in packaging and printing industry, can be detected by high speed printing process color, ink color matching, die cutting, punching, folding conditions; suitable for the textile industry, can detect the spindle rotation and loom weft cloth machine yarn; suitable for mechanical manufacturing industry, observe various rotor, gear machinery manufacturing movement; suitable in chemical, optical, shipbuilding and other industries.
Attention:
1. Insert the power plug slot upwards, do not tighten the plug sleeve, so that the internal connection loose caused by short circuit.
2. When the stroboscope can not work properly, first check the fuse, unplug the power cord, wait 5 minutes after the cover open.
3. When the strobe light leakage may be the lamp aging, please replace the lamp.
4. Lamp cut off the power, there may be charged, non-professionals are not allowed to open.
5. Carefully put, do not fall into the water or solvent, not placed in high temperature and humidity or high pollution environment.
6. During the transportation, the "power switch" must be turned off; when the lamp fails, please remember to turn off the "power switch" to protect the battery.
